Page 150 - 2018 Racecar Engineering Late-Model Muscle Car Parts and Accessories Catalog

Fuel Injectors
Taking an application specific approach, Deatschwerks has delivered upon the need for quality, high
performance fuel injectors, each engineered to provide a direct fit when using the OEM harness, fuel rail and
manifold. Fuel injectors are engineered to deliver higher flow rates, faster response time and compatibility with
race fuels. Set of 8 unless noted.
Application Fuel Injectors Part No. Flow Rate
NEW VENDOR DWK18U-01-0042-8 42 lb./hr.
DWK18U-01-0050-8 50 lb./hr.
DWK18U-01-0060-8 60 lb./hr.
1998-02 Firebird/Trans Am 5.7L LS1 DWK18U-01-0078-8 78 lb./hr.
DWK18U-01-0088-8 88 lb./hr.
DWK17U-05-0095-8 95 lb./hr.
DWK16M-20-1500-8 1500cc

GM LS Reverse Rotation
High Performance Water Pump
Designed for 1997-07 GM LS1 and LS2 engines using
2004-Up two-piece thermostat, two-piece satin finished
aluminum water pump incorporates a 3/4” ball bearing and
measures 6” from the block surface to the hub. Pulley must
be purchased separately.
Part No. Description
EDE8896 GM LS1/LS2, Two-Piece Water Pump
EDE8898 Billet Aluminum Water Pump Pulley, Black Finish, 5.850” Dia.

Pro-Kits
The Eibach Pro-Kit dramatically improves a vehicle's performance and appearance. Often the
huge fender-well gap, inherent from the factory, or performance wheels and tires will give a “lifted”
look. The Pro-Kit reduces the fender gap for a lower, sportier stance. Pro-Kits offer aggressive
good looks and enhanced vehicle handling without compromising safety or ride quality.
Model Year Pro-Kit Front Rear
Firebird And Trans Am, Incl. Convertible 1993-97 EIB3831140 1.3" 1.3"
Firebird And Trans Am V8, Incl. Convertible 1998-02 EIB3870140 1.5" 1.3"
GTO 2004-06 EIB3897140 1.0" 0.8"
G8, 3.6L V6 2008-09 EIB38137140 1.0" 1.0"
G8, 6.0L V8 2008-09 EIB38137140 1.0" 1.0"

Indicate color, -G (Black) or
-R (Red), when ordering.
Example: ENE3-3156-R (red).
Front End Rear End Rear Leaf Front Sway
Control Arm Control Arm Spring Bushing Body Mount Transmission Bar Frame
Year Bushing Set Bushing Set Set Set Mount Bushings Front End Links Tie Rod Boots
32mm
1993-02 — ENE3-3136 — — ENE3-1108 ENE9-8118 ENE9-13101 1
ENE3-5162
Footnotes:
1 Two boots per package.
1993-02 Pontiac Firebird V8 Transmission Mount ENE3-1142
Features Hyper-Flex polyurethane, durable zinc coating and patented interlocking technology.

E3 Spark Plugs
Part No. Description
E3 Spark Plugs’ innovative electrode design adds power, im- E3PE3.54 2008-09 Pontiac G8, 6.0L V8
proves fuel economy and lengthens engine life. Plugs deliver an E3PE3.66 2009 Pontiac G8, 6.2L V8
improved flame that travels quicker and grows larger while traveling E3PE3.54 2005-06 Pontiac GTO, 6.0L V8
toward the piston. The open electrode directly exposes the flame E3PE3.54 2004 Pontiac GTO, 5.7L V8
to the piston during the combustion process, reducing spark travel E3PE3.54 1998-02 Pontiac Firebird, LS1 5.7L V8
time. The “forced, edge-to-edge” spark discharge improves upon E3PE3.44 1994-97 Pontiac Firebird, LT1 5.7L V8
traditional racing spark plugs with “cut back” electrodes. E3PE3.62 1993 Pontiac Firebird, LT1 5.7L V8

PONTIAC PRODUCTS 149
