Pigtail termination in electrical wiring serves the purpose of connecting multiple wires together to a single terminal or connection point. This method helps to simplify the wiring process, reduce the risk of loose connections, and improve the overall reliability of the electrical system.
Properly stripping and preparing the wires for pigtail termination is crucial to ensure a secure and effective connection. To do this, one must carefully strip the insulation from the end of each wire using wire strippers, making sure not to damage the conductors. The exposed wires should then be twisted together tightly and trimmed to a uniform length before attaching them to the terminal.
