Benefits of Professional Dryer Vent Cleaning

Keeping your home clean and tidy goes beyond vacuuming and wiping down surfaces. One often overlooked area that needs professional attention is your dryer vent. While it might seem like a simple task you can handle yourself, professional dryer vent cleaning offers several crucial benefits that contribute to both the safety and efficiency of your home.


First and foremost, professional cleaning significantly reduces the risk of fire. Lint, the primary culprit in dryer vent fires, is highly flammable. Over time, it accumulates in the vent, restricting airflow and creating a hot, dry environment – perfect for ignition. Professionals use specialized tools to thoroughly remove lint buildup, eliminating this fire hazard and providing peace of mind.


Beyond safety, regular cleaning improves dryer efficiency. A clogged vent forces your dryer to work harder and longer to dry clothes. This not only wastes energy and increases your utility bills, but also puts unnecessary strain on the appliance, shortening its lifespan. A clean vent allows for optimal airflow, meaning faster drying times and less wear and tear on your dryer.


Professional cleaners also address issues you might not even be aware of. They can identify and fix problems like kinks in the vent hose or blockages caused by birds nests or other debris. They can also ensure proper vent connection and termination, preventing leaks and further improving drying efficiency.


Finally, a clean dryer vent contributes to a healthier home environment. Lint can carry dust mites, mold spores, and other allergens, which can circulate throughout your home and aggravate allergies or respiratory problems. Professional cleaning removes these irritants, promoting better indoor air quality.


In conclusion, while it might seem like an added expense, professional dryer vent cleaning is a worthwhile investment. It enhances safety by reducing fire risk, improves dryer performance and longevity, addresses potential hidden issues, and contributes to a healthier home. Dont underestimate the importance of this often-overlooked task – its a crucial part of maintaining a safe and efficient home.

Benefits of Professional Dryer Vent Cleaning

Choosing a Qualified Dryer Vent Cleaning Service

Choosing a qualified dryer vent cleaning service isnt exactly glamorous, but its a crucial part of home maintenance that can prevent fires and improve your dryers efficiency. Its easy to overlook this often-hidden chore, but taking the time to find a reputable professional can save you headaches (and potentially money) down the road. So, how do you navigate the world of dryer vent cleaning and choose the right service?


First, resist the urge to simply opt for the cheapest option. While budget is always a consideration, focusing solely on price can lead you to unqualified or even unscrupulous providers. Look for companies that are certified by a reputable organization like the National Air Duct Cleaners Association (NADCA). This certification indicates that the company adheres to industry best practices and has trained technicians. A quick online search can verify a company's credentials.


Next, read reviews. Online reviews can offer valuable insights into a companys reliability, professionalism, and quality of work. Look for patterns in the reviews. A few negative reviews here and there are normal, but a consistent stream of complaints about unprofessional behavior, hidden fees, or incomplete work should raise red flags. Dont hesitate to ask friends, family, and neighbors for recommendations as well. Word-of-mouth referrals can be incredibly helpful.


When you contact a company, ask about their process. A qualified technician should be able to explain how they clean dryer vents, the equipment they use, and the estimated cost. Be wary of companies that offer incredibly low prices or guarantee a specific timeframe without first inspecting the vent. The length and complexity of the job will vary depending on the length and condition of the vent.


Finally, get everything in writing. Before any work begins, ensure you have a written estimate that clearly outlines the scope of work and the total cost. This protects you from unexpected charges and ensures that you and the service provider are on the same page.


Choosing a qualified dryer vent cleaning service requires a little bit of research and due diligence. But by taking the time to find a reputable and experienced professional, you can ensure the safety and efficiency of your dryer and enjoy peace of mind knowing that this important task is handled correctly.

Dryer Vent Cleaning Costs and Frequency

Keeping your dryer running efficiently and safely means paying attention to the often-overlooked dryer vent. While were all good about cleaning the lint trap after each load, a deeper clean of the entire vent system is crucial. But how much does professional dryer vent cleaning cost, and how often should you have it done?


The cost of professional dryer vent cleaning can vary depending on several factors. These include the length and complexity of your vent system, the accessibility of the vent opening, and your geographic location. Generally, you can expect to pay anywhere from $80 to $200 for a standard cleaning. More complex jobs, such as those requiring removal of bird nests or extensive debris, might push the cost higher. Its always a good idea to get multiple quotes from reputable companies in your area.


Now, how often should you schedule this service? The National Fire Protection Association (NFPA) recommends having your dryer vent cleaned at least once a year. However, some situations might warrant more frequent cleanings. For example, if you have a large family and do laundry frequently, or if you notice signs of a clogged vent, like longer drying times, clothes that are unusually hot after a cycle, or a burning smell, you should have it checked sooner. Pets that shed a lot can also contribute to faster lint buildup.


Think of it this way: regular dryer vent cleaning is a small investment that can save you money in the long run. A clogged vent forces your dryer to work harder, using more energy and potentially shortening its lifespan. More importantly, a clean vent significantly reduces the risk of a dryer fire, protecting your home and family. So, while it might seem like just another chore, dryer vent cleaning is a crucial part of home maintenance that shouldnt be ignored.

Maintaining a Clean Dryer Vent: Tips and Best Practices

Maintaining a Clean Dryer Vent: Essential for Safety and Efficiency


As professional cleaners, we often see firsthand the consequences of neglected dryer vents. While seemingly a minor chore, regular dryer vent cleaning is crucial for both safety and efficiency. A clogged vent not only reduces your dryers performance, leading to longer drying times and higher energy bills, but it also presents a serious fire hazard. Lint, the primary culprit, is highly flammable and can easily ignite when trapped in a hot, restricted space like a dryer vent.


So, what are the best practices for maintaining a clean dryer vent? First and foremost, regular cleaning is key. We recommend professional cleaning at least once a year, especially for longer vent runs or homes with pets. However, there are steps you can take between professional cleanings to minimize lint buildup. After each load, remove the lint from the dryers lint trap. This simple act can significantly reduce the amount of lint that makes its way into the vent. Periodically, detach the dryer vent hose and vacuum out any visible lint. You can also use a specialized dryer vent cleaning brush kit to reach further into the vent and dislodge stubborn debris.


Beyond regular cleaning, there are a few other things you can do to promote good dryer vent health. Ensure the vent hose is not kinked or crushed, which can restrict airflow and trap lint. Use rigid metal or semi-rigid aluminum foil ducting instead of flexible plastic or vinyl ducting, as these are more resistant to lint buildup and less likely to sag or become obstructed. Make sure the exterior vent flap opens and closes freely to allow proper airflow and prevent pests from entering.


By following these simple tips and incorporating regular professional cleanings into your home maintenance routine, you can significantly reduce the risk of dryer vent fires and ensure your dryer runs efficiently for years to come. Remember, a clean dryer vent is a safe dryer vent, and professional cleaners are here to help you maintain a safe and efficient home.

Industrial exhaust ducts are pipe systems that connect hoods to industrial chimneys through other components of exhaust systems like fans, collectors, etc. Ducts are low-pressure pneumatic conveyors to convey dust, particles, shavings, fumes, or chemical hazardous components from air in the vicinity to a shop floor or any other specific locations like tanks, sanding machines, or laboratory hoods. Ducts can be fabricated from a variety of materials including carbon steel, stainless steel, PVC, and fiberglass. [1] They can be fabricated through rolling (preferable for ducts of 12" or more in diameter) or extruded (for ducts up to 18").[2]

HVAC systems do not include this category of industrial application, namely exhaust systems. A distinction from HVAC system ducts is that the fluid (air) conveyed through the duct system may not be homogeneous. An industrial exhaust duct system is primarily a pneumatic conveying system and is basically governed by laws of flow of fluids.[3]

Fluid flow

[edit]

The conveying fluid that flows through the duct system is air. Air transports materials from the hood to a destination. It is also instrumental in capturing the material into the flow system. Air is a compressible fluid, but for engineering calculations, air is considered as incompressible as a simplification, without any significant errors.

Design

[edit]

Process design of exhaust system will include

  • Identification of contaminants, their density and size
  • Deciding of air flow
  • Sizing of the ductwork
  • Calculation of resistance
  • Finalizing the capacity of blower, etc.[4]

The goal is to keep contaminants out using minimum airflow. It is estimated that increase in an inch wg[clarification needed] of static pressure can add a few thousands of dollars to the operation cost per annum.

See also

[edit]

References

[edit]
  1. ^ Duct Work Assembly Archived 2020-02-24 at the Wayback Machine U.S. Bellows, (retrieved May 2012)
  2. ^ KCH Engineered Systems
  3. ^ [1] Archived 2015-09-19 at the Wayback Machine ASHRAE Technical Committee 5.2 - Duct Design
  4. ^ [2] Archived 2017-02-20 at the Wayback Machine Industrial Duct System Design Fundamentals

The word duct is derived from the Latin word for led/leading. It may refer to:

  • Duct (anatomy), various ducts in anatomy and physiology
  • Duct (HVAC), for transfer of air between spaces in a structure
  • Duct tape, a kind of adhesive tape
  • Ducted fan, motor for aircraft
  • Electrical bus duct, a metal enclosure for busbars
  • Duct (industrial exhaust), industrial exhaust duct system designed for low pressure-pneumatic convey of gas, fumes, dusts, shavings, and other pollutants from works space to atmosphere after cleaning and removal of contaminants
  • Atmospheric duct, a horizontal layer in the lower atmosphere in which the vertical refractive index gradients are such that radio signals (a) are guided or ducted, (b) tend to follow the curvature of the Earth, and (c) experience less attenuation in the ducts than they would if the ducts were not present
  • Surface duct, a sound propagation phenomenon at sea
  • Duct Publishing, an imprint of the German group VDM Publishing devoted to the reproduction of Wikipedia content
  • Dispatchable Unit Control Table (DUCT) in z/Architecture
  • Flexible Ducting

See also

[edit]

A chimney is an architectural ventilation structure made of masonry, clay or metal that isolates hot toxic exhaust gases or smoke produced by a boiler, stove, furnace, incinerator, or fireplace from human living areas. Chimneys are typically vertical, or as near as possible to vertical, to ensure that the gases flow smoothly, drawing air into the combustion in what is known as the stack, or chimney effect. The space inside a chimney is called the flue. Chimneys are adjacent to large industrial refineries, fossil fuel combustion facilities or part of buildings, steam locomotives and ships.

In the United States, the term smokestack industry refers to the environmental impacts of burning fossil fuels by industrial society, including the electric industry during its earliest history. The term smokestack (colloquially, stack) is also used when referring to locomotive chimneys or ship chimneys, and the term funnel can also be used.[1][2]

The height of a chimney influences its ability to transfer flue gases to the external environment via stack effect. Additionally, the dispersion of pollutants at higher altitudes can reduce their impact on the immediate surroundings. The dispersion of pollutants over a greater area can reduce their concentrations and facilitate compliance with regulatory limits.

History

[edit]

Industrial chimney use dates to the Romans, who drew smoke from their bakeries with tubes embedded in the walls. However, domestic chimneys first appeared in large dwellings in northern Europe in the 12th century. The earliest surviving example of an English chimney is at the keep of Conisbrough Castle in Yorkshire, which dates from 1185 AD,[3] but they did not become common in houses until the 16th and 17th centuries.[4] Smoke hoods were an early method of collecting the smoke into a chimney. These were typically much wider than modern chimneys and started relatively high above the fire, meaning more heat could escape into the room. Because the air going up the shaft was cooler, these could be made of less fireproof materials. Another step in the development of chimneys was the use of built-in ovens which allowed the household to bake at home. Industrial chimneys became common in the late 18th century.

Chimneys in ordinary dwellings were first built of wood and plaster or mud. Since then chimneys have traditionally been built of brick or stone, both in small and large buildings. Early chimneys were of simple brick construction. Later chimneys were constructed by placing the bricks around tile liners. To control downdrafts, venting caps (often called chimney pots) with a variety of designs are sometimes placed on the top of chimneys.

In the 18th and 19th centuries, the methods used to extract lead from its ore produced large amounts of toxic fumes. In the north of England, long near-horizontal chimneys were built, often more than 3 km (2 mi) long, which typically terminated in a short vertical chimney in a remote location where the fumes would cause less harm. Lead and silver deposits formed on the inside of these long chimneys, and periodically workers would be sent along the chimneys to scrape off these valuable deposits.[5]

Construction

[edit]
Chimney in NED University

As a result of the limited ability to handle transverse loads with brick, chimneys in houses were often built in a "stack", with a fireplace on each floor of the house sharing a single chimney, often with such a stack at the front and back of the house. Today's central heating systems have made chimney placement less critical, and the use of non-structural gas vent pipe allows a flue gas conduit to be installed around obstructions and through walls.

Chimney in North London
Flue

Most modern high-efficiency heating appliances do not require a chimney. Such appliances are generally installed near an external wall, and a noncombustible wall thimble[clarification needed] allows a vent pipe to run directly through the external wall.

On a pitched roof where a chimney penetrates a roof, flashing is used to seal up the joints. The down-slope piece is called an apron, the sides receive step flashing and a cricket is used to divert water around the upper side of the chimney underneath the flashing.[6]

Industrial chimneys are commonly referred to as flue-gas stacks and are generally external structures, as opposed to those built into the wall of a building. They are generally located adjacent to a steam-generating boiler or industrial furnace and the gases are carried to them with ductwork. Today the use of reinforced concrete has almost entirely replaced brick as a structural element in the construction of industrial chimneys. Refractory bricks are often used as a lining, particularly if the type of fuel being burned generates flue gases containing acids. Modern industrial chimneys sometimes consist of a concrete windshield with a number of flues on the inside.

The 300 m (980 ft) high steam plant chimney at the Secunda CTL's synthetic fuel plant in Secunda, South Africa consists of a 26 m (85 ft) diameter windshield with four 4.6 metre diameter concrete flues which are lined with refractory bricks built on rings of corbels spaced at 10 metre intervals. The reinforced concrete can be cast by conventional formwork or sliding formwork. The height is to ensure the pollutants are dispersed over a wider area to meet legal or other safety requirements.

Residential flue liners

[edit]

A flue liner is a secondary barrier in a chimney that protects the masonry from the acidic products of combustion, helps prevent flue gas from entering the house, and reduces the size of an oversized flue. Since the 1950s, building codes in many locations require newly built chimneys to have a flue liner. Chimneys built without a liner can usually have a liner added, but the type of liner needs to match the type of appliance it services. Flue liners may be clay or concrete tile, metal, or poured in place concrete.

Clay tile flue liners are very common in the United States, although it is the only liner that does not meet Underwriters Laboratories 1777 approval and frequently they have problems such as cracked tiles and improper installation.[7] Clay tiles are usually about 2 feet (0.61 m) long, available in various sizes and shapes, and are installed in new construction as the chimney is built. A refractory cement is used between each tile.

Metal liners may be stainless steel, aluminum, or galvanized iron and may be flexible or rigid pipes. Stainless steel is made in several types and thicknesses. Type 304 is used with firewood, wood pellet fuel, and non-condensing oil appliances, types 316 and 321 with coal, and type AL 29-4C is used with high efficiency condensing gas appliances. Stainless steel liners must have a cap and be insulated if they service solid fuel appliances, but following the manufacturer's instructions carefully.[7] Aluminum and galvanized steel chimneys are known as class A and class B chimneys. Class A are either an insulated, double wall stainless steel pipe or triple wall, air-insulated pipe often known by its genericized trade name Metalbestos. Class B are uninsulated double wall pipes often called B-vent, and are only used to vent non-condensing gas appliances. These may have an aluminum inside layer and galvanized steel outside layer.

Concrete flue liners are like clay liners but are made of a refractory cement and are more durable than the clay liners.

Poured in place concrete liners are made by pouring special concrete into the existing chimney with a form. These liners are highly durable, work with any heating appliance, and can reinforce a weak chimney, but they are irreversible.

Chimney pots, caps, and tops

[edit]

A chimney pot is placed on top of the chimney to expand the length of the chimney inexpensively, and to improve the chimney's draft. A chimney with more than one pot on it indicates that multiple fireplaces on different floors share the chimney.

A cowl is placed on top of the chimney to prevent birds and other animals from nesting in the chimney. They often feature a rain guard to prevent rain or snow from going down the chimney. A metal wire mesh is often used as a spark arrestor to minimize burning debris from rising out of the chimney and making it onto the roof. Although the masonry inside the chimney can absorb a large amount of moisture which later evaporates, rainwater can collect at the base of the chimney. Sometimes weep holes are placed at the bottom of the chimney to drain out collected water.

A chimney cowl or wind directional cap is a helmet-shaped chimney cap that rotates to align with the wind and prevent a downdraft of smoke and wind down the chimney.

An H-style cap is a chimney top constructed from chimney pipes shaped like the letter H. It is an age-old method of regulating draft in situations where prevailing winds or turbulences cause downdraft and back-puffing. Although the H cap has a distinct advantage over most other downdraft caps, it fell out of favor because of its bulky design. It is found mostly in marine use but has been regaining popularity due to its energy-saving functionality. The H-cap stabilizes the draft rather than increasing it. Other downdraft caps are based on the Venturi effect, solving downdraft problems by increasing the updraft constantly resulting in much higher fuel consumption.

A chimney damper is a metal plate that can be positioned to close off the chimney when not in use and prevent outside air from entering the interior space, and can be opened to permit hot gases to exhaust when a fire is burning. A top damper or cap damper is a metal spring door placed at the top of the chimney with a long metal chain that allows one to open and close the damper from the fireplace. A throat damper is a metal plate at the base of the chimney, just above the firebox, that can be opened and closed by a lever, gear, or chain to seal off the fireplace from the chimney. The advantage of a top damper is the tight weatherproof seal that it provides when closed, which prevents cold outside air from flowing down the chimney and into the living space—a feature that can rarely be matched by the metal-on-metal seal afforded by a throat damper. Additionally, because the throat damper is subjected to intense heat from the fire directly below, it is common for the metal to become warped over time, thus further degrading the ability of the throat damper to seal. However, the advantage of a throat damper is that it seals off the living space from the air mass in the chimney, which, especially for chimneys positioned on an outside of wall of the home, is generally very cold. It is possible in practice to use both a top damper and a throat damper to obtain the benefits of both. The two top damper designs currently on the market are the Lyemance (pivoting door) and the Lock Top (translating door).

In the late Middle Ages in Western Europe the design of stepped gables arose to allow maintenance access to the chimney top, especially for tall structures such as castles and great manor houses.

Chimney draught or draft

[edit]

When coal, oil, natural gas, wood, or any other fuel is combusted in a stove, oven, fireplace, hot water boiler, or industrial furnace, the hot combustion product gases that are formed are called flue gases. Those gases are generally exhausted to the ambient outside air through chimneys or industrial flue-gas stacks (sometimes referred to as smokestacks).

The combustion flue gases inside the chimneys or stacks are much hotter than the ambient outside air and therefore less dense than the ambient air. That causes the bottom of the vertical column of hot flue gas to have a lower pressure than the pressure at the bottom of a corresponding column of outside air. That higher pressure outside the chimney is the driving force that moves the required combustion air into the combustion zone and also moves the flue gas up and out of the chimney. That movement or flow of combustion air and flue gas is called "natural draught/draft", "natural ventilation", "chimney effect", or "stack effect". The taller the stack, the more draught or draft is created. There can be cases of diminishing returns: if a stack is overly tall in relation to the heat being sent out of the stack, the flue gases may cool before reaching the top of the chimney. This condition can result in poor drafting, and in the case of wood burning appliances, the cooling of the gases before emission can cause creosote to condense near the top of the chimney. The creosote can restrict the exit of flue gases and may pose a fire hazard.

Designing chimneys and stacks to provide the correct amount of natural draft involves a number of design factors, many of which require iterative trial-and-error methods.

As a "first guess" approximation, the following equation can be used to estimate the natural draught/draft flow rate by assuming that the molecular mass (i.e., molecular weight) of the flue gas and the external air are equal and that the frictional pressure and heat losses are negligible: where:

  • Q = chimney draught/draft flow rate, m3/s
  • A = cross-sectional area of chimney, m2 (assuming it has a constant cross-section)
  • C = discharge coefficient (usually taken to be from 0.65 to 0.70)
  • g = gravitational acceleration, 9.807 m/s2
  • H = height of chimney, m
  • Ti = average temperature inside the chimney, K
  • Te = external air temperature, K.

Combining two flows into chimney: At+Af<A, where At=7.1 inch2 is the minimum required flow area from water heater tank and Af=19.6 inch2 is the minimum flow area from a furnace of a central heating system.

Draft hood

[edit]

Gas fired appliances must have a draft hood to cool combustion products entering the chimney and prevent updrafts or downdrafts.[8][9][10]

Maintenance and problems

[edit]

A characteristic problem of chimneys is they develop deposits of creosote on the walls of the structure when used with wood as a fuel. Deposits of this substance can interfere with the airflow and more importantly, they are combustible and can cause dangerous chimney fires if the deposits ignite in the chimney.

Heaters that burn natural gas drastically reduce the amount of creosote buildup due to natural gas burning much cleaner and more efficiently than traditional solid fuels. While in most cases there is no need to clean a gas chimney on an annual basis that does not mean that other parts of the chimney cannot fall into disrepair. Disconnected or loose chimney fittings caused by corrosion over time can pose serious dangers for residents due to leakage of carbon monoxide into the home.[11] Thus, it is recommended—and in some countries even mandatory—that chimneys be inspected annually and cleaned on a regular basis to prevent these problems. The workers who perform this task are called chimney sweeps or steeplejacks. This work used to be done largely by child labour and, as such, features in Victorian literature. In the Middle Ages in some parts of Europe, a stepped gable design was developed, partly to provide access to chimneys without use of ladders.

Masonry (brick) chimneys have also proven to be particularly prone to crumbling during earthquakes. Government housing authorities in cities prone to earthquakes such as San Francisco, Los Angeles, and San Diego now recommend building new homes with stud-framed chimneys around a metal flue. Bracing or strapping old masonry chimneys has not proven to be very effective in preventing damage or injury from earthquakes. It is now possible to buy "faux-brick" facades to cover these modern chimney structures.

Other potential problems include:

  • "spalling" brick, in which moisture seeps into the brick and then freezes, cracking and flaking the brick and loosening mortar seals.
  • shifting foundations, which may degrade integrity of chimney masonry
  • nesting or infestation by unwanted animals such as squirrels, racoons, or chimney swifts
  • chimney leaks
  • drafting issues, which may allow smoke inside building[12]
  • issues with fireplace or heating appliance may cause unwanted degradation or hazards to chimney

Chimneys of special interest

[edit]

Chimneys with observation decks

[edit]

Several chimneys with observation decks were built. The following possibly incomplete list shows them.

Name Country Town Coordinates Year of completion Total height Height of observation deck Remarks
Chimney of Beitou Refuse Incineration Plant Taiwan Teipei 25°06′29″N 121°29′58″E / 25.108043°N 121.499384°E / 25.108043; 121.499384 (Chimney of Beitou Refuse Incineration Plant) 2000 150 m (492 ft) 116 m (381 ft) revolving restaurant in a height of 120 metres (394 ft)
Radio City Tower United Kingdom Liverpool   53°24′23″N 2°58′55″W / 53.406332°N 2.982002°W / 53.406332; -2.982002 (Radio City Tower) 1971 148 m (486 ft) 124.7 m (409 ft) chimney for the heating system of a nearby mall
Large Chimney of Warsaw Refuse Incineration Plant Poland Warsaw   52°15′41″N 21°06′18″E / 52.261448°N 21.105072°E / 52.261448; 21.105072 (Large Chimney of Warsaw Refuse Incineration Plant) 2024 72 m (236 ft)   observation deck only accessible at guided tours through the facility
Bernard Brewery Chimney Czech Humpolec   49°32′23″N 15°21′36″E / 49.539786°N 15.360043°E / 49.539786; 15.360043 (Bernard Brewery Chimney)   40.7 m (134 ft) 33 m (108 ft) observation deck added in 2020/21
Dům DÄ›tí a Mládeže v ModÅ™anech Czech Prague   50°00′44″N 14°24′49″E / 50.012154°N 14.413657°E / 50.012154; 14.413657 (Dům DÄ›tí a Mládeže v ModÅ™anech) 2004 15 m (49 ft) 12 m (39 ft) observation platform on chimney of the roof of a youth centre
Chimney of Zenner Heating Building Germany Berlin   52°29′17″N 13°28′38″E / 52.488097°N 13.477282°E / 52.488097; 13.477282 (Chimney of Zenner Heating Building) 1955 15 m (49 ft) 12 m (39 ft) perhaps never in use as observation tower

Chimneys used as electricity pylon

[edit]

At several thermal power stations at least one smokestack is used as electricity pylon. The following possibly incomplete list shows them.

Country City Coordinates Name Height Year of construction Voltage Remarks
Germany Gelsenkirchen   51°36′02″N 7°00′16″E / 51.600623°N 7.004573°E / 51.600623; 7.004573 (Scholven Power Station, Chimney for Units B, C, D and E) Scholven Power Station, Chimney for Units B, C, D and E 300 m   220 kV
Belarus Novolukoml   54°40′45″N 29°08′09″E / 54.679048°N 29.135925°E / 54.679048; 29.135925 (Lukoml Power Station, Chimney 1) Lukoml Power Station, Chimney 1 250 m 1969 330 kV
Belarus Novolukoml   54°40′48″N 29°08′07″E / 54.679941°N 29.135259°E / 54.679941; 29.135259 (Lukoml Power Station, Chimney 2) Lukoml Power Station, Chimney 2 250 m 1971 330 kV
Belarus Novolukoml   54°40′53″N 29°08′04″E / 54.681290°N 29.134428°E / 54.681290; 29.134428 (Lukoml Power Station, Chimney 3) Lukoml Power Station, Chimney 3 250 m 1973 330 kV
Lithuania Elektrenai   54°46′17″N 24°38′50″E / 54.771463°N 24.647291°E / 54.771463; 24.647291 (ElektrÄ—nai Power Plant, Chimney 1) ElektrÄ—nai Power Plant, Chimney 1 150 m   330 kV dismantled
Lithuania Elektrenai   54°46′12″N 24°38′48″E / 54.770110°N 24.646765°E / 54.770110; 24.646765 (ElektrÄ—nai Power Plant, Chimney 2) ElektrÄ—nai Power Plant, Chimney 2 250 m   330 kV dismantled
Moldova Dnestrovsc   46°37′40″N 29°56′23″E / 46.627864°N 29.939691°E / 46.627864; 29.939691 (Cuciurgan power station, Chimney 1) Cuciurgan power station, Chimney 1 180 m 1964 110 kV
Moldova Dnestrovsc   46°37′44″N 29°56′23″E / 46.628880°N 29.939622°E / 46.628880; 29.939622 (Cuciurgan power station, Chimney 2) Cuciurgan power station, Chimney 2 180 m 1966 330 kV
Moldova Dnestrovsc   46°37′49″N 29°56′23″E / 46.630199°N 29.939622°E / 46.630199; 29.939622 (Cuciurgan power station, Chimney 3) Cuciurgan power station, Chimney 3 180 m 1971 330 kV
Russia Archangelsk   64°34′29″N 40°34′24″E / 64.574788°N 40.573261°E / 64.574788; 40.573261 (Archangelsk Cogeneration Plant, Chimney 1) Archangelsk Cogeneration Plant, Chimney 1 170 m   220 kV
Russia Saint Petersburg   59°58′14″N 30°22′35″E / 59.970595°N 30.376425°E / 59.970595; 30.376425 (Vyborgskaya Cogenaration Plant, Chimney 1) Vyborgskaya Cogenaration Plant, Chimney 1 120 m   110 kV
Russia Tobolsk   58°14′44″N 68°26′43″E / 58.245439°N 68.445224°E / 58.245439; 68.445224 (Tobolsk Cogeneration Plant, Chimney 1) TEC Tobolsk, Chimney 1 240 m 1980 110 kV
Russia Tobolsk   58°14′45″N 68°26′55″E / 58.245781°N 68.448590°E / 58.245781; 68.448590 (Tobolsk Cogeneration Plant, Chimney 2) TEC Tobolsk, Chimney 2 270 m 1986 220 kV
Russia Kashira   54°51′24″N 38°15′23″E / 54.856639°N 38.256428°E / 54.856639; 38.256428 (Kashira Power Plant, Chimney 1) Kashira Power Plant, Chimney 1 250 m 1966 220 kV
Russia Energetik   51°45′12″N 58°48′09″E / 51.753324°N 58.802583°E / 51.753324; 58.802583 (Iriklinskaya Power Station, Chimney 1) Iriklinskaya Power Station, Chimney 1 180 m   220 kV
Russia Energetik   51°45′12″N 58°48′14″E / 51.753453°N 58.803983°E / 51.753453; 58.803983 (Iriklinskaya Power Station, Chimney 2) Iriklinskaya Power Station, Chimney 2 180 m   220 kV
Russia Energetik   51°45′13″N 58°48′22″E / 51.753483°N 58.806183°E / 51.753483; 58.806183 (Iriklinskaya Power Station, Chimney 3) Iriklinskaya Power Station, Chimney 3 250 m   500 kV
Russia Konakovo   56°44′23″N 36°46′22″E / 56.739703°N 36.772833°E / 56.739703; 36.772833 (Konakovo Power Station, Chimney 1) Konakovo Power Station, Chimney 1 180 m 1964 220 kV
Russia Konakovo   56°44′26″N 36°46′20″E / 56.740627°N 36.772308°E / 56.740627; 36.772308 (Konakovo Power Station, Chimney 2) Konakovo Power Station, Chimney 2 180 m 1966 220 kV
Russia Koryazhma   61°18′09″N 47°07′13″E / 61.302456°N 47.120396°E / 61.302456; 47.120396 (Chimney 1 of Cogenaration Plant 1 of Kotlas Pulp and Paper Mill) Chimney 1 of Cogenaration Plant 1 of Kotlas Pulp and Paper Mill 105 m 1961 220 kV
Ukraine Burshtyn   49°12′27″N 24°40′03″E / 49.207578°N 24.667450°E / 49.207578; 24.667450 (Burshtyn Power Station, Chimney 1) Burshtyn Power Station, Chimney 1 180 m 1965 330 kV
Ukraine Burshtyn   49°12′31″N 24°39′57″E / 49.208595°N 24.665921°E / 49.208595; 24.665921 (Burshtyn Power Station, Chimney 2) Burshtyn Power Station, Chimney 2 250 m 1966 330 kV
Ukraine Burshtyn   49°12′34″N 24°39′54″E / 49.209334°N 24.664918°E / 49.209334; 24.664918 (Burshtyn Power Station, Chimney 3) Burshtyn Power Station, Chimney 3 250 m 1966 330 kV
Ukraine Trypillia   50°08′01″N 30°44′52″E / 50.133591°N 30.747659°E / 50.133591; 30.747659 (Trypillia Power Station, Chimney 1) Trypillia Power Station, Chimney 1 180 m 1968 330 kV
Ukraine Trypillia   50°08′00″N 30°44′44″E / 50.133239°N 30.745553°E / 50.133239; 30.745553 (Trypillia Power Station, Chimney 2) Trypillia Power Station, Chimney 2 180 m 1972 330 kV

Nearly all this structures exist in an area, which was once part of the Soviet Union. Although this use has the disadvantage that conductor ropes may corrode faster due to the exhaust gases, one can find such structures also sometimes in countries not influenced by the former Soviet Union. An example herefore is one chimney of Scholven Power Plant in Gelsenkirchen, which carries one circuit of an outgoing 220 kV-line.

Chimneys used as water tower

[edit]

Chimneys can also carry a water tank on their structure. This combination has the advantage that the warm smoke running through the chimney prevents the water in the tank from freezing. Before World War II such structures were not uncommon, especially in countries influenced by Germany.

Chimneys used as radio tower

[edit]

Chimneys can carry antennas for radio relay services, cell phone transmissions, FM-radio and TV on their structure. Also long wire antennas for mediumwave transmissions can be fixed at chimneys. In all cases it had to be considered that these objects can easily corrode especially when placed near the exhaust. Sometimes chimneys were converted into radio towers and are not useable as ventilation structure any more.

Chimneys used for advertising

[edit]

As chimneys are often the tallest part of a factory, they offer the possibility as advertising billboard either by writing the name of the company to which they belong on the shaft or by installing advertisement boards on their structure.

Cooling tower used as an industrial chimney

[edit]

At some power stations, which are equipped with plants for the removal of sulfur dioxide and nitrogen oxides, it is possible to use the cooling tower as a chimney. Such cooling towers can be seen in Germany at the Großkrotzenburg Power Station and at the Rostock Power Station. At power stations that are not equipped for removing sulfur dioxide, such usage of cooling towers could result in serious corrosion problems which are not easy to prevent.

See also

[edit]

References

[edit]
  1. ^ C.F. Saunders (1923), The Southern Sierras of California
  2. ^ "Jules Verne (1872), Around the World in Eighty Days". Retrieved 2006-07-30.
  3. ^ James Burke, Connections (Little, Brown and Co.) 1978/1995, ISBN 0-316-11672-6, p. 159
  4. ^ Sparrow, Walter Shaw. The English house: how to judge its periods and styles. London: Eveleigh Nash, 1908. 85–86.
  5. ^ "Lead Mining". The Northern Echo. Newsquest Media Group. Retrieved 10 April 2012.
  6. ^ Roofing, flashing & waterproofing. Newtown, CT: Taunton Press, 2005. 43–50.
  7. ^ a b Bliss, Stephen, ed.. Troubleshooting guide to residential construction: the diagnosis and prevention of common building problems. Richmond, VT: Builderburg Group, 1997. 197. Print.
