Etched Glass
Decorative Doors and Inserts
Etched Glass
Construction Options and
Modifications
These glass designs offer etched linear patterns or an overall fine, sanded texture into which a pattern or shape is etched. Patterns
range from mullions to simple shapes. Visibility of cabinetry interiors is possible when some areas of the glass are left unetched.
Etched glass is available in most door styles, in sizes from 12” wide and up to 54” high.
Glass inserts are ordered individually. Place quantity before order code. See examples for individual items.
Material dimensions listed may vary slightly from actual dimensions of the product.
See Construction Options section for specific information on each glass type.
Specifications subject to change without notice.
1 PRA 1
quantity
code
height code
Crossroads Insert
15” - 33” H
1CRO1
2CRO1
3CRO1
4CRO1
36” - 54” H
1CRO2
2CRO2
3CRO2
4CRO2
• Clear tempered glass
• 3/16˝ frosted etched groove
• Recommended for square door styles only
• Only available on doors 15” x 15” and larger
•
Not
available on 24” or 27” wide BUTT doors
•
Not
available in High-Gloss Laminate door styles
• Order Example: W1830L-1CRO1
Lisbon Insert
12” - 33” H
1LIS1
2LIS1
3LIS1
4LIS1
36” - 54” H
1LIS2
2LIS2
3LIS2
4LIS2
• Obscure safety glass
• 3/8” silhouette etched groove with polished center
and frosted edges
•
Not
available in High-Gloss Laminate door styles
•
Not
available in Woodgrain Laminate slab door styles
• Order Example: W1830R-1LIS1
Modern Frosted Insert
12” - 33” H
1MRF1
2MRF1
3MRF1
4MRF1
36” - 54” H
1MRF2
2MRF2
3MRF2
4MRF2
• Etched tempered glass
• 1˝ clear bevel
• Available in full overlay door styles only
•
Not
available in High-Gloss Laminate door styles
•
Not
available in Woodgrain Laminate slab door styles
•
Not
available in arch door styles
•
Not
available with applied molding doors
• Order Example: W1830R-1MRF1
