G43
Bayshore Collection (S3)
Vanity Cabinets
Bayshore
Collection (S3)
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Available in full overlay door styles only.
All Decorative Accent Vanities come with a matching 1/2˝ plywood toe kick as
standard.
Decorative Skirts add 1 5/16” to the frame width
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
VCDF 60 18 34 •S3
code width depth height series
Bayshore Collection (S3)
• The carved linear column detail and tapered feet are
reminiscent of classic, fine furniture design
• Large Cove Molding (LCVM) is applied to tops of Vanity
Walls and Mirrors; a solid wood plate with a single bead
edge is applied to the bottom
• 1 1/2” carved linear column side accents
• Toe kick accent includes 3/4”, single bead edged plate,
and carved details on tapered legs
• Toe kick skirt ships separately for field installation
• Door style and finish combinations will drive the styling
of these pieces from soft modern to classic
Vanity Sink Base Single Door w/Decorative Accents Bayshore Collection (S3)
Specify R or L
VSB241834 R or L•S3
VSB242134 R or L•S3
• Single door and drawer front
• Available in Alder–Rustic, Cherry, EverCore™,
Laminate and Maple and full overlay door
styles only
• Painted hardwood supplied for EverCore™
and Laminate
• Optional Utensil Trays (UT and SUT) are
available
• Optional Door Storage Unit (SBDSU) is
available
l
APFC
v
FPEB
l
MI
l
DE
l
RD
l
TWR
WR
XS
l
GD
RTK
VTK
18˝ 21˝
34 ½˝
Vanity Sink Base Double Door w/Decorative Accents Bayshore Collection (S3)
s
VSB271834 •S3
s
VSB301834 •S3
VSB331834 •S3
VSB361834 •S3
VSB391834 •S3
s
VSB272134 •S3
s
VSB302134 •S3
VSB332134 •S3
VSB362134 •S3
VSB392134 •S3
• Single drawer front
• Available in Alder–Rustic, Cherry, EverCore™,
Laminate and Maple and full overlay door
styles only
• Painted hardwood supplied for EverCore™
and Laminate
• Optional Utensil Trays (UT and SUT) are
available
• Optional Door Storage Unit (SBDSU) is
available
• Skirt ships separately
l
APFC
v
FPEB
l
MI
l
DE
l
RD
l
TWR
WR
XS
l
GD
RTK
VTK
18˝ 21˝
34 ½˝
s
Sink Base Door Storage Unit (SBDSU)
not
available
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
RD Reduced Depth
TWR Top Wide Rail
WR Wide Bottom Rail
XS
Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
VTK Void Toe Kick
