343 / 601
G22
Vanity Cabinets
Vanity Cabinets
Vanity Utility Cabinet 21” Deep
Specify R or L
84” High
i
VU92184 R or L
VU122184 R or L
VU152184 R or L
VU182184 R or L
VU212184 R or L
VU242184 R or L
VU242184 BUTT
VU272184 (Butt)
VU302184 BUTT
VU332184 BUTT
VU362184 BUTT
87” High
i
VU92187 R or L
VU122187 R or L
VU152187 R or L
VU182187 R or L
VU212187 R or L
VU242187 R or L
VU242187 BUTT
VU272187 (Butt)
VU302187 BUTT
VU332187 BUTT
VU362187 BUTT
90” High
i
VU92190 R or L
VU122190 R or L
VU152190 R or L
VU182190 R or L
VU212190 R or L
VU242190 R or L
VU242190 BUTT
VU272190 (Butt)
VU302190 BUTT
VU332190 BUTT
VU362190 BUTT
93” High
i
VU92193 R or L
VU122193 R or L
VU152193 R or L
VU182193 R or L
VU212193 R or L
VU242193 R or L
VU242193 BUTT
VU272193 (Butt)
VU302193 BUTT
VU332193 BUTT
VU362193 BUTT
96” High
i
VU92196 R or L
VU122196 R or L
VU152196 R or L
VU182196 R or L
VU212196 R or L
VU242196 R or L
VU242196 BUTT
VU272196 (Butt)
VU302196 BUTT
VU332196 BUTT
VU362196 BUTT
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Factory installed Roll-out Trays (ROT) are
not
available on Utility Cabinets wider than 24˝
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
I
Glass doors available for top doors only
I
When Inverted Frame (IF) is chosen in arched
door styles, VU18, VU24, VU24BUTT and
VU36 cabinets will have arched doors. All
other cabinet sizes will be supplied with
square doors
I
Operational End (OE) is
not
available with
Increased Depth (ID) or Reduced Depth (RD)
options
I
Maximum Increased Depth (ID) is 24”
I
Wide Bottom Rail (WR) and Recessed Toe Kick (RTK)
not
available on 93” & 96” high cabinets
I
Void Toe Kick (VTK) is
not
available on 93” and 96”
high cabinets
•
Not
available in Hailey door styles
•
Note:
Shelf Kit (SK) for lower section
must
be ordered
separately; see Shelving section of this book
Remember to order a 3/16” skin (WSK) for
the exposed ends of 93” & 96” high cabinets
to conceal the seam between the loose toe
kick and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
OE
I
RD
I
ID
I
IF
TWR
I
WR
l
XS
I
GD
I
RTK
I
VTK
84˝
87˝
90˝
93˝
96˝
21˝
VU9-24
21˝
23 ½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
VU24 BUTT -
VU27 BUTT
21˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
VU30-36
New
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
Gray color coding indicates new product, size or code.
