E41
Base Specialty Cabinets
Base Cabinets
Base Specialty
Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
RD Reduced Depth
IF
Inverted Frame
TWR Top Wide Rail
WR Wide Bottom Rail
XS
Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
RTKP Recessed Toe Kick Peninsula
VTK Void Toe Kick
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
BKSD 36 24 29
code
width depth height
Base Wine Rack
BWR6
• Wood veneer construction with 1/2” end
panels
• Four fixed shelves
• Bottle stop pin placed at 12” (removable)
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
• Vinyl edge banding applied to edges of
cabinet
• Recommended installation is between two
cabinets
I
Minimum Reduced Depth (RD) is 12˝ for
laminate door styles; 6” for wood door styles
I
Only available with Recessed Toe
Kick Peninsula Back (RTKP);
cannot
accommodate Recessed Toe Kick for sides
(RTKPB, RTKPL, RTKPR)
•
Note:
This cabinet features “frameless” type
construction
PE
APC
APFC
FPEB
v
MI
DE
I
RD
IF
TWR
WR
XS
GD
RTK
I
RTKP
l
VTK
34
1
/
2
˝
24˝
Base Filler Pull-out
BFP3
1 3/4” shelf width
BFP6
4 3/4” shelf width
• Three adjustable shelves
• Unit slides on full extension side-mount
runners
• Recommended installation is between two
cabinets
• Installation may also be made between a
cabinet and a wall or a cabinet and an end
panel with stile
• Filler is included, but unattached. Unit
should be installed before removing shipping
brace and attaching filler
• A filler overlay is recommended for full
overlay door styles;
must
be ordered
separately
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
• No toe kick
Do
not
use filler pullouts (WFP, BFP,
BSPP) at the end of cabinet runs or
next to appliances. They
must
be
installed between two cabinets or a cabinet
and an end panel.
Consider using a Replacement
Drawer Front (RDW3006) on a Base
Filler Pullout (BFP) as an overlay for
1/2” door styles.
PE
APC
APFC
FPEB
MI
DE
RD
IF
TWR
WR
XS
GD
RTK
RTKP
VTK
30˝
23¾˝
Install decorative hardware prior
to attaching filler to pull-out unit
Side View
Filler
Filler
