222 / 601
D63
Wall Accessories
Wall Cabinets
Matching Wall End Panel
Specify R or L
MWEP12 R or L
MWEP15 R or L
MWEP18 R or L
MWEP24 R or L
MWEP30 R or L
MWEP33 R or L
MWEP36 R or L
MWEP39 R or L
MWEP42 R or L
s
MWEP48 R or L
s
MWEP54 R or L
Double Panel & Stack
snu=
MWEPDP54 R or L
Peninsula
n
PMWEP12
n
PMWEP15
n
PMWEP18
n
PMWEP24
n
PMWEP30
n
PMWEP33
n
PMWEP36
n
PMWEP39
n
PMWEP42
• 3/4” thick
• Inside of matching panel bottom
rail will line up with inside
bottom rail of door
• Left shown
• Field installation only
• Laminate, mitered and slab door
styles do
not
have grooves and
will
not
fit flush against 1/2”
end panel. A 3/16” shim is
recommended
• Peninsula panel has routed door
profile front and back
•
Not
available in High-Gloss Laminate door
styles
•
Not
available in Sturbridge Oak Square
When designing with Matching End
Panels the reveal will differ from the
cabinet door height reveal. Matching
End Panels cover the entire side of
the cabinet. See drawing for exact
measurements
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
11 / ˝
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
¾˝
/ ˝
54˝
11 / ˝
MWEPDP54
s
Available in full overlay door styles only
n
Not
available in Woodgrain Laminate door styles
u
Not
available in mitered door styles
=
Not
available in slab door styles
Matching Wall End Panel–Square Edges
MWEP12 S
MWEP15 S
MWEP18 S
MWEP24 S
MWEP30 S
MWEP33 S
MWEP36 S
MWEP39 S
MWEP42 S
s
MWEP48 S
s
MWEP54 S
Double Panel & Stack
su
MWEPDP54 S
• 3/4˝ thick panel with square edge
front and back
• Inside of matching panel bottom
rail will line up with inside
bottom rail of door
• Reversible, may be used on either
right or left end
• Field installation only
• No frame recess dado
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in mitered door styles
•
Not
available in Sturbridge Oak Square
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
11 / ˝
Will not fit flush against ½˝ end
panel; a ⁄
˝ shim is recommended
54˝
11 / ˝
MWEPDP54S
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
s
Available in full overlay door styles only
u
Not
available in slab door styles
Furniture Matching Wall End Panel
Specify R or L
FMWEP12 R or L
FMWEP15 R or L
FMWEP18 R or L
FMWEP24 R or L
FMWEP30 R or L
FMWEP33 R or L
FMWEP36 R or L
FMWEP39 R or L
FMWEP42 R or L
s
FMWEP48 R or L
s
FMWEP54 R or L
Double Panel & Stack
su=
FMWEPDP54 R or L
Peninsula
FPMWEP12
FPMWEP15
FPMWEP18
FPMWEP24
FPMWEP30
FPMWEP33
FPMWEP36
FPMWEP39
FPMWEP42
• 3/4” thick
• Inside of matching panel bottom
rail will line up with inside
bottom rail of door
• Left shown
• Field installation only
• Peninsula panel has routed door
profile front and back
• For use with Furniture Plywood Ends
(FPEB)—flush ends
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Sturbridge Oak Square
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
11 / ˝
54˝
11 / ˝
FMWEPDP54
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
s
Available in full overlay door styles only
u
Not
available in mitered door styles
=
Not
available in slab door styles
Overlay Panel For Wall Blind Corner Cabinets
OPWBC24
OPWBC30
OPWBC33
OPWBC36
OPWBC39
OPWBC42
OPWBC48
OPWBC54
• Available in full overlay door
styles only
• Overlay Panel has routed door
profile and is made from the
same material as doors and
drawer fronts
• Field miter
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
9˝
23 / ˝
29 / ˝
32 / ˝
35 / ˝
38 / ˝
41 / ˝
47 / ˝
53 / ˝
