C30
Construction Options
Specifications and Options
Void Top Drawer Box
VTDW
• This option removes top drawer box and
runner system on multi-drawer stacks
• Drawer fronts will be attached as a false front
•
Note
: This option will affect the top drawer
only on a cabinet
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
Void All Drawer Boxes
VDW
• This option removes all drawer boxes and
runner systems
• Drawer fronts will be attached as a false front
•
Note
: This option will affect all drawers on a
cabinet. You
cannot
specify single drawers
on a multi-drawer cabinet
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
Prep for Warming Drawer
PWD
• This option removes the center drawer box,
drawer front and runner system of a BPPS
to allow for field installation of a warming
drawer only
• Check manufacturer’s requirements before
ordering
• Available on BPPS 24–36, BPPSCC and
BPPSFCC
• Order Example: BPPS 30-PWD
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
22
25
˝ 9
Cabinet Min
Wd
Max
Wd
Min
Ht
Max
Ht
BPPS24
21˝ 22½˝ 9½˝
10˝
BPPS27
24˝ 25½˝ 9½˝
10˝
BPPS30
27˝ 28½˝ 9½˝
10˝
BPPS33
BPPS(F/CC)30
BPPS(F/CC)33
BPPS(F/CC)36
30˝ 31½˝ 9½˝
10˝
Cut out dimensions
21˝
½ ˝ 9½˝
10˝
24˝
½˝ 9½˝
10˝
27˝ 28½
½˝
10˝
BPPS36
36˝ 34½ ˝ 9½˝
10˝
Scoop Top Drawer
STDW
• Reduced height drawer box for top drawer of
base cabinet only
• 4˝ high drawer box reduced to 2 1/4˝ solid
wood
• 7˝ high drawer box reduced to 4˝ solid wood
• 11˝ high drawer box reduced to 7˝ plywood
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
