Vanity Cabinets
G9
Vanity Cabinets
Vanity Combination Drawer (8)
Specify R or L
18” Deep
Drawer-Door-Drawer
s
VCD421834 R or L•8
12˝-18˝-12˝
s
VCD451834 R or L•8
12˝-21˝-12˝
VCD481834 •8
12˝-24˝-12˝
VCD511834 •8
12˝-27˝-12˝
VCD541834 •8
15˝-24˝-15˝
VCD571834 •8
15˝-27˝-15˝
s
VCD601834 •8
15˝-30˝-15˝
21” Deep
s
VCD422134 R or L•8
12˝-18˝-12˝
s
VCD452134 R or L•8
12˝-21˝-12˝
VCD482134 •8
12˝-24˝-12˝
VCD512134 •8
12˝-27˝-12˝
VCD542134 •8
15˝-24˝-15˝
VCD572134 •8
15˝-27˝-15˝
s
VCD602134 •8
15˝-30˝-15˝
• Six standard drawers
• Two deep drawers
• Scoop Top Drawer (STDW) option available
• Optional Vanity Wood Tiered Drawer
Storage (VWTDS) and Vanity Adjustable
Drawer Divider (VADD) are available.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
ID
IF
l
TWR
l
WR
l
XS
l
GD
l
RTK
l
VTK
34 ½˝
VCD42-45
VCD48-60
34 ½˝
18˝, 21˝
18˝, 21˝
s
Optional Door Storage Unit (SBDSU) is
available
CoreGuard® Vanity
VSB302134 •CG
VSB332134 •CG
VSB362134 •CG
• Easy to clean and durable sink base helps
protect the cabinetry from everyday leaks
and spills
• Back, end and bottom panels are made of an
engineered polymer material
• Bottom panel slants 1º toward front of
cabinet and has raised ribs to slightly elevate
stored items
• Decorative end panel required for end of
peninsula or island.
Not
Included, order
separately
• No shelf
• One full-width false drawer front above
doors
• Optional Door Storage Unit (SBDSU) is
available
• Optional Utensil Trays (UT and SUT) are
available
• Will
not
accept Roll-out Trays (ROT)
• Includes a Touch-Up Kit (TUK)
Caution:
For an island/peninsula
installation, the CoreGuard® Sink
cabinet
must
have a minimum of
one (1) 15” cabinet or larger installed adjacent
to it in order for the island/peninsula to have
adequate structural stability. Accessories
cannot
be installed on end panels, back or
floor of the cabinet
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
l
TWR
WR
l
XS
GD
RTK
VTK
Opening Sizes
Cabinet
Top Width Top Depth
VSB302134.CG
VSB332134.CG
VSB362134.CG
27 ⁄
”
19 ⅜˝
30 ⁄
”
19 ⅜˝
33 ⁄
”
19 ⅜˝
34
1
/
2
˝
21 ˝
