Vanity Cabinets
G3
Vanity Cabinets
Vanity Sink Base Four Drawer
18” Deep
VSB601834 •4
21” Deep
VSB602134 •4
• Two pair of butt doors
• Four drawer stack in center
• Three standard height drawers
• One deep drawer
• Two drawer fronts
• Scoop Top Drawer (STDW) option available
• Optional Vanity Wood Tiered Drawer
Storage (VWTDS) and Vanity Adjustable
Drawer Divider (VADD) are available.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
ID
IF
l
TWR
l
WR
l
XS
l
GD
l
RTK
l
VTK
34 ½˝
18˝, 21˝
Console Vanity
Classic Leg
VCN242134 R or L•CLS
VCN302134 •CLS
VCN362134 •CLS
VCN422134 •CLS
VCN482134 •CLS
Plain Square Post
VCN242134 R or L•PSP
VCN302134 •PSP
VCN362134 •PSP
VCN422134 •PSP
VCN482134 •PSP
Roman Spindle
VCN242134 R or L•RSP
VCN302134 •RSP
VCN362134 •RSP
VCN422134 •RSP
VCN482134 •RSP
Sterling Leg
VCN242134 R or L•STL
VCN302134 •STL
VCN362134 •STL
VCN422134 •STL
VCN482134 •STL
Tapered Leg
VCN242134 R or L•TPL
VCN302134 •TPL
VCN362134 •TPL
VCN422134 •TPL
VCN482134 •TPL
• Available in full overlay door styles only
• Available in Cherry, EverCore™, High-Gloss
Laminate, Laminate, and Maple full overlay
door styles only
• Painted hardwood supplied for EverCore™
and Laminates
• Open area height from top of bottom shelf
to cabinet frame is 13”
• Plumbing cutout is centered; measures 4 1/4”
x 10”
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Console Vanity Deluxe Roll-Out Tray
(CDXROT) is available for factory or field
installation in 30”, 36” and 42” VCN wide
cabinets
For a finished look, we recommend
attaching replacement doors to the
end panels (RD1515NH.B — sold
separately, qty. 2 needed if covering both
ends)
In order to complete the furniture
look on your console vanity, limit
your countertop overhang to 1/8”
on the front and both sides. A standard size
vanity countertop will work with the console
vanity, but keep in mind the countertop
overhang to the front will only be 1/8”;
overhang on the sides will be 1/2”. Be sure to
account for the positioning of the vanity bowl
in relation to the cabinet. If you use a large
vanity bowl or if your bowl is positioned too
far forward, you may need to notch the inside
top rail of the frame in order to accommodate
the bowl.
PE
APC
v
APFC
FPEB
v
MI
DE
RD
ID
IF
TWR
WR
XS
GD
RTK
VTK
34 ½˝
15
¾˝
14
/ ˝
13
/ ˝
34 ½˝
21˝
21˝
VCN24
VCN
30-48
/ ˝
CLS
34 ½˝
RSP
34 ½˝
PSP
34 ½˝
TPL
34 ½˝
STL
34 ½˝
