Specifications and Options
C2
Cabinet Specs
Material thickness dimensions may be nominal based on lumber industry standards
Cabinet Specifications
• (1) Viraguard clad back panel
• (2) 1/2” wood concealed hanging rail
• (3) 1/2” Natural Birch Viraguard clad ceiling panel
• (4) 3/4˝ solid Alder, Birch, Cherry, Hickory, Maple and
Oak front frame constructed using industrial grade
glue and hardened steel fasteners. Front frame species
complements selected door style.
• (5) Extensive and unique door style and wood species
selection in Alder, Birch, Cherry, EverCore™, Hickory,
Maple and Oak. Solid and wood veneer construction
available. Also available in Laminate and High-Gloss
Laminate.
• (6) Satin chrome shelf rests for all kitchen wall and
furniture cabinets. Easily adjustable positive locking
shelf clips for all base, tall and vanity cabinets.
• (7) Natural Birch Viraguard interior.
• (8) 3/4” fully adjustable Natural Birch Viraguard clad
shelving standard feature in wall, base and tall cabinets.
• (9) 1/2” Natural Birch Viraguard clad cabinet bottom
• (10) 14-step Durakraft Plus™ furniture process featuring
hand-wiped stain with one of the finest wood finishes
available in the cabinet industry
• (11) Full-depth I-beam braces provide stability and
convenient anchor points for countertop
• (12) 3/8” Natural Birch Viraguard clad base back panel
• (13) 3/4” solid wood base installation rail
• (14) Standard drawer runner suspension system
features smooth, ball bearing operation with a 90
pound load capacity. Whisper Touch™ runner has an
integrated drawer buffer that engages two inches from
closing and applies resistance, giving a soft, controlled
closing.
• (15) 3/4” full-depth solid wood dovetailed drawer
featuring four sided construction and 3/16” plywood
bottom
• (16) Self-closing, concealed, wrap-around adjustable or
optional knife hinges (KH)
• (17) Full-depth, fully adjustable 3/4” Natural Birch
Viraguard clad shelving
• (18) Drawer heads are solid hardwood or laminate to
complement each door style.
• (19) Fully closed toe space area.
• (20) 1/2˝ end panels with woodgrain Viraguard
interior and matching Alder, Birch, Cherry, Hickory,
Laminate, Maple or Oak exterior. Also available with
optional 1/2˝ or 3/4˝ plywood end panels. Woodgrain
Viraguard interior or wood veneer interior available.
Unless noted, plain sawn end panels will be supplied
for quartersawn door styles.
• Viraguard is the tradename of our printed wood grain
laminate
8
7
3
2
1
4
10
9
5
6
12
14
20
13
15
19
17
11
18
6
16
Concealed Hinge
Knife Hinge
KraftMaidCabinetry
is also available in an All Plywood (APC) Option.
See Construction Options section for a complete description.
90 pound load capacity
