Vanity Cabinets
G98
Vanity Cabinet Accessories
Vanity Curved End Panel
VEP32134 CEP
• 5/8” wood veneer construction
• Reversible, may be used on either right or left end
• Curved matching toe kick included and shipped
separately
•
Not
available in Alder–Rustic door styles
• Painted hardwood supplied for EverCore™
•
Not
available in Morristown; Brockton, Melrose and
Putnam Oak supplied plain sawn
PE
APC
APFC
FPEB
MI
CW
RD
CH
WR
VTK
21˝
21˝
3˝
34 ½˝
Matching Vanity End Panel
MVEP1834 R or L
MVEP2134 R or L
• 3/4” thick panel with matching door edge profile on front edge
only
• Inside of matching panel bottom rail will line up with
inside bottom rail of door
• Left shown
• Laminate and slab door styles do
not
have grooves
and will
not
fit flush against 1/2˝ end panel. A 3/16˝
shim is recommended.
•
Not
available in mitered door styles; use End Panel–
Mitered
•
Not
available in Morristown; Brockton, Melrose and
Putnam Oak supplied plain sawn
I
Wide Bottom Rail—field notch for toe kick
When designing with Matching End Panels the reveal
will differ from the cabinet door height reveal.
Matching End Panels cover the entire side of the
cabinet. See drawing for exact measurements
PE
APC
APFC
FPEB
MI
CW
RD
CH
I
WR
VTK
¾˝
Standard edge detail — fits flush against
1/2˝ end panel and behind face frame
17 / ˝, 20 /
34 ½˝
/
Matching Vanity End Panel–Square Edges
MVEP1834 •S
MVEP2134 •S
• 3/4˝ thick panel with square edge front and back
• Inside of matching panel bottom rail will line up with
inside bottom rail of door
• Reversible, may be used on either right or left end
• No frame recess dado
• Field installation only
•
Not
available in Laminate door styles
•
Not
available in mitered door styles; use End Panel–
Mitered
•
Not
available in Morristown; Brockton, Melrose and Putnam
Oak supplied plain sawn
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
CW
RD
CH
I
WR
VTK
Will not fit flush
against 1/2˝ end panel,
a 3/16˝ shim is recommended
17 / ˝, 20 /
34 ½˝
Furniture Matching Vanity End Panel
FMVEP1834 R or L
FMVEP2134 R or L
• 3/4” thick panel with matching door edge profile on
front edge only
• Inside of matching panel bottom rail will line up
with inside bottom rail of door
• For use with Furniture Plywood Ends (FPEB)—flush
ends
• Left shown
• Field installation only
•
Not
available in mitered door styles; use End Panel–Mitered
•
Not
available in Morristown; Brockton, Melrose and Putnam
Oak supplied plain sawn
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
CW
RD
CH
I
WR
VTK
17 / ˝, 20 /
34 ½˝
