Tall Cabinets
F30
Tall Cabinet Accessories
Universal Tall End Panel
UTEP2484
UTEP2487
UTEP2490
UTEP2493
UTEP2496
• 3/4” thick frame with square recessed panel
• Field installation only
• Reversible, may be used on either right or
left end
•
Not
available in Laminate door styles
•
Not
available in Morristown; Brockton,
Melrose and Putnam Oak supplied plain
sawn
I
Wide Bottom Rail—field notch for toe kick
Do
not
order a Universal Tall End Panel
(UTEP) when using Matching Wall and Base
End Panels (MWEP and MBEP) in the rest of
the kitchen. UTEP’s do
not
have a matching profile,
therefore, they will
not
match the doors.
PE
APC
APFC
FPEB
MI
CW
RD
CH
I
WR
VTK
¾˝
3
/
16
˝
11 / ˝
23 / ˝
84˝
87˝
90˝
93˝
96˝
Gray color coding indicates new product, size or code.
Recessed Matching Tall End Panel
60 1/2” High
RMTEP1260 •M
RMTEP2460 •M
84” High
RMTEP1284 •M
RMTEP2484 •M
87” High
RMTEP1287 •M
RMTEP2487 •M
90” High
RMTEP1290 •M
RMTEP2490 •M
93” High
RMTEP1293 •M
RMTEP2493 •M
96” High
RMTEP1296 •M
RMTEP2496 •M
• 3/4” thick
• Quartersawn solid wood
• Recessed panel grain runs horizontally
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Field installation only
• Reversible, may be used on either right or
left end
• Available in Morristown door style only
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
CW
RD
CH
I
WR
VTK
Will not fit flush against 1/2˝end panel,
a 3/16˝ shim is recommended
11 / ˝
23 / ˝
84˝
87˝
90˝
93˝
96˝
Gray color coding indicates new product, size or code.
Corner Tall End Panel
Wood Veneer
Width x Height x Thickness
WCTEP84
23 1/8” x 84” x 1/2”
WCTEP87
23 1/8” x 87” x 1/2”
WCTEP90
23 1/8” x 90” x 1/2”
WCTEP93
23 1/8” x 93˝ x 1/2”
WCTEP96
23 1/8” x 96” x 1/2”
• See Option #2 in Diagonal Installation of
Standard Tall Cabinets in the back of this
section
• Quartersawn Cherry and Maple door styles
supplied plain sawn
• Painted hardwood supplied for EverCore™
• Corner Tall End Panel (CTEP) and Corner
Tall Molding (CTM8) are sold separately
PE
l
APC
APFC
FPEB
MI
CW
RD
CH
WR
VTK
23
1
/
8
˝
CTEP
CTM8
CTEP
84˝
87˝
90˝
93˝
96˝
Gray color coding indicates new product, size or code.
