Tall Cabinets
F28
Tall Cabinet Accessories
Refrigerator End Panel w/Stile
32” Deep
84” High
DREP1 1/2•84
DREP3•84
87” High
DREP1 1/2•87
DREP3•87
90” High
DREP1 1/2•90
DREP3•90
93” High
DREP1 1/2•93
DREP3•93
96” High
DREP1 1/2•96
DREP3•96
108” High
I
DREP1 1/2•108
I
DREP3•108
120” High
I
DREP1 1/2•120
I
DREP3•120
24” Deep
84” High
REP1 1/2•84
REP3•84
87” High
REP1 1/2•87
REP3•87
90” High
REP1 1/2•90
REP3•90
93” High
REP1 1/2•93
REP3•93
96” High
REP1 1/2•96
REP3•96
108” High
I
REP1 1/2•108
I
REP3•108
120” High
I
REP1 1/2•120
I
REP3•120
• Reversible
• Exterior finished to match, interior is
Natural Birch Viraguard
• Painted hardwood supplied for EverCore™
l
PE
l
APC
l
APFC
l
FPEB
l
MI
CW
l
RD
l
CH
WR
VTK
24˝, 32˝
84˝
87˝
90˝
93˝
96˝
108˝
120˝
I
Matching Interior All Plywood Furniture
Construction (MIAPFC) standard on these sizes only
Gray color coding indicates new product, size or code.
Tall Curved End Panel
TEP3•1284CEP
TEP3•2484CEP
TEP3•1290CEP
TEP3•2490CEP
TEP3•1296CEP
TEP3•2496CEP
• 5/8” wood veneer construction
• Reversible, may be used on either right or
left end
• Curved matching toe kick included and
shipped separately
•
Not
available in Alder–Rustic door styles
• Painted hardwood supplied for EverCore™
•
Not
available in Morristown; Brockton,
Melrose and Putnam Oak supplied plain
sawn
PE
APC
APFC
FPEB
MI
CW
RD
CH
WR
VTK
84˝
90˝
96˝
12˝,24˝
3˝
Matching Tall End Panel
60 1/2” High
MTEP1260 R or L
MTEP2460 R or L
84” High
MTEP1284 R or L
MTEP2484 R or L
87” High
MTEP1287 R or L
MTEP2487 R or L
90” High
MTEP1290 R or L
MTEP2490 R or L
93” High
MTEP1293 R or L
MTEP2493 R or L
96” High
MTEP1296 R or L
MTEP2496 R or L
• 3/4” thick panel with matching door
edge profile on front edge only
• Inside of matching panel bottom rail will
line up with inside bottom rail of door
• Left shown
• Field installation only
•
Not
available in Morristown
•
Not
available in Laminate door styles
•
Not
available in mitered door styles; use
End Panel–Mitered
•
Not
available in slab door styles
I
Wide Bottom Rail—field notch for toe kick
When designing with Matching End Panels
the reveal will differ from the cabinet door
height reveal. Matching End Panels cover
the entire side of the cabinet. See drawing for exact
measurements
PE
APC
APFC
FPEB
MI
CW
RD
CH
I
WR
VTK
Standard edge detail—fits flush against
1/2˝ end panel and behind face frame
11 / ˝
23 / ˝
11 / ˝
¾˝
23 / ˝
60
1
/
2
˝
84˝
87˝
90˝
93˝
96˝
/ ˝
Gray color coding indicates new product, size or code.
