M11
Door & Drawer Fronts - Sizes
Replacement Parts
All replacement doors and drawer fronts by their nomenclature. They are sorted by their nominal height (last two
numbers of the nomenclature) from largest to smallest.
To choose doors and drawer fronts for special decorative applications, look in the appropriate overlay column to
determine which doors and drawer fronts are needed.
How to Use This Section
Replacement Door & Drawer Front Information
Replacement doors may be ordered for wall or base application.
When ordering, specify door style, hinging and •W (wall) or •B
(base). Any arch doors ordered as •B will be shipped in a square
design.
Example:
You need a replacement door for a wall 1830, hinged left.
Order: RD1830L•W
Replacement doors are prepared for hing-
es. Replacement door and drawer fronts
are automatically drilled for PermaSet
bumpers. If a door is specified for no hinge
(NH), the door is drilled in all four corners
for bumpers (bumpers are included) and
will also receive a single cup hinge bore for internal tracking
purposes.
Replacement doors with glass inserts or mullion inserts installed
are available on doors 12˝ or wider up to 42˝ high.
To order, determine the replacement door(s) required and add
desired glass insert or mullion insert.
Example:
You need a Chateau glass insert for a wall 1830, hinged
left.
Order:
RD1830L•W–1CHA1
Pricing:
RD1830L•W
+ 1 Chateau Insert for 12”- 30”high
= Total for replacement door
with insert installed
Example:
You need a Mullion insert for a wall 1836, hinged left.
Order:
RD1836L•W–1MD2
Pricing:
RD1836L•W
+ 1 Mullion Insert for 36” - 42” high
= Total for mullion door
with insert installed
Replacement doors and drawer fronts are coded for easy refer-
ence. The prefix codes indicate door or drawer and usage. The
first two digits indicate nominal width and the second two digits
indicate nominal height.
RD 18 30
Prefix
Nominal
Nominal
code
Width
Height
Prefix codes are as follows:
RD replacement door
RDA replacement door angle
RDAAG replacement door angle appliance garage
RDADP replacement door angle double panel
RDAG replacement door appliance garage
RDB replacement door butt
RDBDP replacement door butt double panel
RDBI
replacement door base inside angle
RDBO replacement door base outside angle
RDDEZR*
replacement door desk easy reach
(two doors hinged together)
RDDP replacement door double panel
RDE replacement door operational end
RDEZR*
replacement door easy reach
(two doors hinged together)
RDLS replacement door lazy susan
(two doors mitered together)
RDM replacement door multi-storage
pantry (door storage unit attached)
RDMC replacement door mirror cabinet
RDW replacement drawer front
RDWA replacement drawer front angle
RDWBCD replacement drawer front base corner drawer
RDWEZR*
replacement door wall easy reach
(two doors hinged)
RDWFD replacement door wall furniture drawer
RDWI
replacement door wall inside angle
RDWLBF replacement door wall lateral bifold cabinet
RDWO replacement door wall outside angle
RDWTHG replacement door wall top hinge
RDWWHV replacement drawer front wall hung vanity
RDWZ*
replacement door wall easy reach
(individual doors)
RDZ*
replacement door easy reach
(individual doors)
RDZA replacement door “Z” angle
* See notes on next page for RDZ doors.
