M3
Hardware
Replacement Parts
Rear Adjustment Adapter - Full Extension Heavy Duty Under Mount
Soft-close Guides
PHDFXSCRMB
• Attaches using the guide holes in the back of the
cabinet
• Used on Base Pots and Pans Storage (BPPS) cabinets
• Includes a left and right rear adjustment adapter
• One set per carton
170 Degree Hinge
RH170EZ
• Nickel plated finish
• Includes hinge and mounting plate
• Used on Traditional and Full Overlay Base Corner
Revolving (BCR) and Lazy Susan (LS)
• Offered individually
Bi-Fold Hinge
RHBF
• Nickel plated finish
• Includes hinge and mounting plate
• Used on Traditional and Full Overlay Base Corner
Revolving (BCR) and Lazy Susan (LS)
• Offered individually
Face Mount Hinge
PHFM •SC
Soft-Close 6-Way
PHFM
6-Way
• Nickel plated finish
• Soft-close hinges have soft-close action; standard hinges
do
not
• Used on 1/2” and full overlay Wall Microwave Cabinet
(WMC) and Oven Cabinet Universal (O_U) cabinets
• Offered as a pair
Gray color coding indicates new product, size or code.
