Base Cabinets
E36
Base End Run Cabinets
Base End Corner w/Curved Door
BEC24 •CDO
• 23 5/8” radius
• Two adjustable shelves
• Two convex doors with 3” center stile
• Can be installed on either right or left end
• For Curved Moldings, see Molding section of
this book
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Available in Bradford, Marquette Cherry
Roman (Full & Half) and Marquette Cherry
Square (Full & Half)
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
CH
WR
GD
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
24˝
Base Z-Angle
Specify R or L
BZA12 R or L
• Right shown
• Two adjustable shelves
• One optional tray divider available in center
location only
•
Not
available in Laminate door styles
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Doors will
not
receive pegs when ordered in
Abington, LaSalle & Morristown door styles
• Outside profile will contain eased edges and
will
not
match straight doors for Rutherford,
Lindsay and Northwicke door styles
•
Not
available in Brockton, Eldridge, Fox
Chase Roman (Half & Full), Fox Chase Square
(Half & Full), Garrison, Harlowe, Harrington,
Jamison, Judson, Kendrick, Lincoln, North
Hampton, Patterson, Putnam, Richland, Seton,
Smithton, Tennyson & Vanderbilt
I
Minimum Reduced Depth (RD) is 12˝
I
Recessed Toe Kick (RTK) available hinge side only
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
I
RD
CH
WR
GD
I
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
12˝
18˝
18˝
12˝
24˝
3˝
8
1
/
2
˝
3˝
Base End Open Shelf 24” Deep
Specify R or L
BEOS624 R or L
BEOS924 R or L
BEOS1224 R or L
• 5/8” wood veneer construction
• 1 3/16˝ thick bottom shelf
• Three fixed shelves
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• For Curved Moldings, see Molding section of
this book
• Painted hardwood supplied for EverCore™
•
Not
available in Morristown; Brockton,
Melrose and Putnam Oak supplied
quartersawn
I
Reduced Depth (RD) available in 3”
increments to a minimum of 12”
• Example: BEOS 1224R-RD reduce depth to 18˝
PE
l
APC
APFC
FPEB
v
MI
DE
CW
I
RD
CH
WR
GD
RTK
RTKP
l
VTK
Left shown
34 ½˝
24˝
9 / ˝
9 / ˝
11 / ˝
9 / ˝
24˝
6˝
R
24˝
9˝
4¾˝
4¾˝
R
24˝
12˝
R
Base End Open Shelf Mission 24” Deep
Specify R or L
BEOS624 R or L•M
BEOS924 R or L•M
BEOS1224 R or L•M
• Three fixed shelves
• 1 1/4” thick bottom shelf
• Quartersawn wood veneer construction
• Available in quartersawn Oak door styles
only
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
I
Reduced Depth (RD) available in 3”
increments to a minimum of 12”
• Example: BEOS 1224R.M-RD reduce depth to
18˝
PE
l
APC
APFC
FPEB
v
MI
DE
CW
I
RD
CH
WR
GD
RTK
RTKP
l
VTK
6˝, 9˝, 12˝
Left shown
34 ½˝
9 / ˝
9 / ˝
9 / ˝
