Base Cabinets
E33
Peninsula Base Corner Cabinets
Peninsula Easy Reach Super Susan
Specify R or L Rear Frame Position
Iu
PEZR33 RR or L•SS
Iu
PEZR33 LR or L•SS
i
PEZR36 RR or L•SS
i
PEZR36 LR or L•SS
• Two pie-cut 30 5/8” diameter, Viraguard
interior rotating shelves
• Rotating shelves are attached to cabinet floor
and fixed shelf
• Shelves rotate independently
• Lazy Susan
cannot
be turned from peninsula
side with kitchen side doors in closed
position
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Doors are profiled on one long and two short
edges and are connected with hinges
• The first R or L designates kitchen side door
hinging
• The second R or L designates rear (peninsula)
frame position
• Butt doors on peninsula side
• 31˝ door clearance recommended for delivery
• Toe kick is detachable
• Example shown: PEZR33RL
•
Note
: Kitchen side does
not
include Soft-Close
feature. Peninsula side doors feature Soft-Close
hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
CW
RD
l
CH
IF
TWR
WR
l
XS
I
GD
RTK
v
RTKP
VTK
34
1
/
2
˝
24˝
33˝, 36˝
33˝, 36˝
I
Glass doors
not
available on kitchen side
u
Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel on kitchen
side. Courtney doors will have a veneer,
recessed flat panel on kitchen side.
i
Not
available with Aluminum Frame glass
doors on kitchen side
Peninsula Easy Reach Wood Super Susan
Specify R or L Rear Frame Position
Iu
PEZR33 RR or L•WSS
Iu
PEZR33 LR or L•WSS
i
PEZR36 RR or L•WSS
i
PEZR36 LR or L•WSS
• Two pie-cut shelves rotate individually
• EZR33 has 28˝ diameter shelves; EZR36 has
32˝ diameter shelves
• Rotating shelves are attached to cabinet floor
and fixed shelf
• Shelves rotate independently
• Lazy Susan
cannot
be turned from peninsula
side with kitchen side doors in closed
position
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Doors are profiled on one long and two short
edges and are connected with hinges
• The first R or L designates kitchen side door
hinging
• The second R or L designates rear (peninsula)
frame position
• Butt doors on peninsula side
• 31˝ door clearance recommended for delivery
• Toe kick is detachable
• Example shown: PEZR33RL
•
Note
: Kitchen side does
not
include Soft-Close
feature. Peninsula side doors feature Soft-Close
hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
CW
RD
l
CH
IF
TWR
WR
l
XS
I
GD
RTK
v
RTKP
VTK
34
1
/
2
˝
24˝
33˝, 36˝
33˝, 36˝
I
Glass doors
not
available on kitchen side
u
Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel on kitchen
side. Courtney doors will have a veneer,
recessed flat panel on kitchen side.
i
Not
available with Aluminum Frame glass
doors on kitchen side
