Replacement Parts
M8
Full Extension Under Mount Guide Kit
PFXSCDR18
PFXSCDR21
PFXSCDR24
• 75 lbs. capacity
• Full extension guide, pulls out past the face
frame
• Kit includes left and right guides and
mounting hardware
• 18 deep used on 18” deep cabinets
• 21 deep used on 21” deep cabinets
• 24 deep used on 24” deep cabinets
• One kit per carton
Full Extension Under Mount Peninsula Base Guide Kit
PFXSCDRPB24
• 75 lbs. capacity
• Full extension guide, pulls out past the face
frame
• 24 deep used on 24” deep cabinets
• One kit per carton
Full Extension Heavy Duty Under Mount Guide Set
PHDFXSCDR24
• 75 lbs. capacity
• Full extension guide, pulls out past the face
frame
• Set includes left and right guides
• Used on Base Pots and Pans Storage (BPPS)
cabinets
• Offered as a pair
Locking Device - Full Extension Heavy Duty Under Mount Guides
Left
HDFXSCDC •L
Right
HDFXSCDC •R
• Used on Base Pots and Pans Storage (BPPS)
cabinets
• One per carton
left shown
right shown
