Below is a diagram of terminology used for the various steel frame components to assist you in comparing quotes between shed companies. Shed kits and cabin kits of today, do most definitely reduce construction time, and Jamaica Cottage Shops techniques, though they include timber frame and post and beam construction of old, do not require fancy skills.
Jamaica Cottage Shop has delivered upwards of 6000-7000 buildings, and kits, in the 20+ years they have been in business. A plan view drawing showing the diameter, location and projection of all anchor rods for the components of the Metal Building System and may show column reactions (magnitude and direction).
A set of drawings that may include framing plans, elevations and sections through the building for approval of the buyer. Any panel that has a primary purpose of the aesthetic enhancement of a building or structure. Wire mesh used to prevent birds from entering the building through ventilators and louvers.
The weight of the Building System construction consisting of members such as framing and covering.
A frame located at the endwall of a building that supports the loads from a portion of the end bay.
The engineer or architect who is responsible for the overall design of the building project.


The on-site assembling of fabricated Metal Building System components to form a completed structure. Roof and wall erection (framing) drawings that identify individual components and accessories furnished by the manufacturer in sufficient detail to permit proper erection of the Metal Building System. The dimension of the building measured perpendicular to the main framing from end wall to end wall. A steep sloped (almost vertical) real or mock roof element on the perimeter of a building.
A sign attached to the peak of the building at the endwall identifying the building manufacturer.
When designing a shed the engineering varies according to regional wind speed and use of the building. When getting your quotes for your building it is a good idea to enquire about the engineering steps and what effects the size of building you are requesting has upon component sizes and thicknesses as a change in height or span of a few millimetres can save you several hundred dollars or even thousands on a large project. This also is why you can find price differences in some sheds where the engineers of one brand will only sign off on certain standards where other engineers are prepared to sign off on a little lesser in material strength for the same job. This entry was posted in Shed Building, shed engineering, Shed Terminology, Sheds garages carports and tagged engineering, engineering step, shed engineering, steel shed building. Middle class Victorians ordered pre-cut building kits, and parts (like porches) by mail order, and received them by boat and rail.


Most often the estimated assembly times are for one or two people, with only basic carpentry skills, from 10 hours for 1 person to put together an outhouse shed, 2 people at 32 hours for a cabin, and 2 people at 40 hours for a cottage. Attachment An Attachment is a building which will attach to any other building in the project. The other areas that affect the engineering are changing a sheds span, bay size and wall height affects the required engineering. Increase the size of a sheds span and wall height and that takes the materials up to the next step and the thickness might increase to 1.5mm or the perhaps c200 might be required. Whilst it is not always the case, often, when you are paying a little extra for what appears to be the same size building, what you are paying for is an extra grade of engineering in the form of additional material or connections in the engineering. The frames of an attachment that is a lean-to must line up with the columns lines of the building to which it attaches.
Any other building type can attach to another building anywhere along the wall to which it attaches.
