INSTALLATION

1. Remove the oil pump cover assembly.

2. Install the high pressure pump (5) sprocket.

NOTE: The crankshaft sprocket bolt is a left handed thread.

3. Install the crankshaft sprocket.

4. Install the timing belt. (Refer to 9 - ENGINE/VALVE TIMING/TIMING BELT/CHAIN AND SPROCKETS - REMOVAL)
5. Install the cooling fan and fan drive viscous clutch assembly
6. Install the accessory drive belt
7. Connect negative battery cable.
