INSTALLATION




1. Install the latch screws (4) and tighten to 8 Nm (71 in. lbs.) top screws first.
2. Connect the electrical connector.
3. Connect the rods and seat the clips fully.



4. Install the rear exterior handle nut (2) and tighten to 4.5 Nm (40 in. lbs.).





5. Install the trim panel (1),
(Refer to 23 - BODY/DOOR - HALF REAR/TRIM PANEL - INSTALLATION).
