BULB

CAUTION: Always use the correct bulb size and type for replacement. An incorrect bulb size or type may overheat and cause damage to the lamp, the socket or the lamp wiring.

NOTE: The following procedure applies only to vehicles manufactured for export markets. Rear fog lamps are not available in vehicles manufactured for domestic markets.

1. Reach under and behind the outboard end of the rear bumper cover (1) to access the take out and connector (4) of the rear bumper wire harness connected to the rear fog lamp bulb socket near the back of the lamp housing.
2. Align the base of the bulb with the lamp socket.
3. Push the bulb straight into the socket until the base is firmly seated.
4. Align the socket and bulb with the keyed opening on the back of the rear fog lamp housing.
5. Insert the socket and bulb into the housing until the socket is firmly seated.
6. Rotate the socket clockwise about 30 degrees to lock it into place.
7. Reconnect the battery negative cable.
