Security Considerations

How to read this

Hereafter we try list potential security concerns when dealing with the various Arrow specifications. Some of these concerns will apply directly to users of Arrow through existing implementations. Others should only be relevant for the implementors of Arrow libraries: by this, we mean libraries that provide APIs abstracting away from the details of the Arrow formats and protocols.

Columnar Format

The Arrow columnar format involves direct access to the process’ address space. As such, in-memory Arrow data should not be accessed without care.

Invalid data

Reading and interpreting Arrow data involves reading into several buffers, sometimes in non-trivial ways. This may for instance involve data-dependent indirect addressing: to read a value from a Binary array, you need to 1) read its offsets in buffer #2, and 2) read the range of bytes delimited by these offsets in buffer #3. If the offsets are invalid (deliberately or not), then step 2) can access invalid memory (potentially crashing the process) or memory unrelated to Arrow (potentially allowing an attacker to exfiltrate confidential data).

Advice for users

If you receive Arrow in-memory data from an untrusted source, it is extremely recommended that you first validate the data for structural soundness before reading it. Many Arrow implementations provide APIs to do such validation.

Advice for implementors

It is recommended that you provide APIs to validate Arrow data, so that users can assert whether data coming from untrusted sources can be safely accessed.

Uninitialized data

A less obvious pitfall is when some parts of an Arrow array are left uninitialized. For example, if a element of a primitive Arrow array is marked null through its validity bitmap, the corresponding value in the values buffer can be ignored for all purposes. It is therefore tempting, when creating an array with null values, to not initialize the corresponding value slots.

However, this then introduces a serious security if the Arrow data is serialized and published such that it can be accessed by untrusted users. Indeed, the uninitialized value slot can reveal data left by a previous memory allocation made in the same process. Depending on the application, this data could contain confidential information.

Advice for users and implementors

When creating a Arrow array, it is recommended that you never leave any data uninitialized in a buffer if the array might be sent to, or read by, a untrusted third-party, even when the uninitialized data is logically irrelevant. The easiest way to do this, though perhaps not the most efficient, is to zero-initialize any buffer that will not be populated in full.

Note

Sending Arrow data out of the current process can happen indirectly, for example if you produce it over the C Data Interface and the consumer persists it using the IPC format on some public storage.

C Data Interface

The C Data Interface contains raw pointers into the process’ address space. It is generally not possible to validate that those pointers are legitimate; read from such a pointer may crash or access unrelated or bogus data.

If you produce a C Data Interface structure for data that nevertheless comes from an untrusted source (for example because you are writing a proxy to an arbitrary third-party service), it is recommended that you validate the data first, as the consumer may assume that the data is valid already.

You should never consume a C Data Interface structure from an untrusted producer.

When consuming a C Data Interface structure, you can assume that it comes from a trusted producer, for the reason explained above. However, it is still recommended that you validate it for soundness, as a trusted producer can have bugs anyway.

IPC Format

The IPC format is a serialization format for the columnar format with associated metadata. Reading an IPC stream or file from an untrusted source comes with similar caveats as reading the Arrow columnar format.

The additional signalisation and metadata in the IPC format come with its own risks. For example, offsets and sizes encoded in IPC messages may be out of bounds for the IPC stream; Flatbuffers-encoded payloads may carry incorrect offsets pointing outside of the IPC stream.

As with the columnar format, it is extremely recommended that you validate any Arrow data read from the IPC format if it comes from an untrusted source.

It is extremely recommended to run additional validation checks when decoding the IPC format, to make sure that the decoding can not induce unwanted behavior (such as crashing or accessing unrelated memory when decoding a Flatbuffers payload).
