finishing the side of a cabinet
Standard Cabinet
Add Furniture Plywood Ends
(FPEB)
Add Furniture Matching End Panel
(FM_EP_R or L)
Add Furniture Plywood Ends And Replacement Door
(FPEB/RD_NH)
Add Beaded/V-Groove Panel And Transition Molding
(BEPL/VGRPL & TRM8)
Recess The Toe Kick
For A Custom Look
Add Wood Skin
(WSK)
Add Matching End Panel
(M_EP_R or L)
Add Wood Skin And Replacement Door
(WSK/RD_NH)
Add Integrated Decorative End
(DBE/DTE/DVE/DWE)
• Features matching Viraguard
1/2" sides
• Standard 1/8" reveal between
face frame and cabinet side
• WSK1230 will flush out 1/2"
side and eliminate side/face
frame reveal
• Allows flexibility of finishing/
flushing only one end of
the cabinet
• Creates a wood veneer finished
end that will age/change with the
face frame and doors instead of
standard Viraguard
• Field installed
• Designed with groove to fit the
reveal on standard 1/2" sides
(see spec book for exceptions)
• Matching end panel covers the
entire side of the cabinet
• Field installed
• Wood skin flushes end to allow
replacement door to lie flat on
side of cabinet
• Matches cabinet door reveal, top
and bottom, for a uniform look
• Field installed
• Decorative door is built into the
end panel of the cabinet for a
custom look
• Protrudes an additional 1/16" past
cabinet dimension, fitting nicely
on tight ends of runs where the
wall ends
• Cabinet will feature a matching
interior as standard with this option
• See spec book for more
information about this option
• Factory installed
• Increases 1/2" engineered wood
ends to 3/4" plywood ends
• Creates a flush end and
eliminates side/face frame reveal
• Finished wood end will age/
change with face frame and doors
• Factory installed
• Designed to be used with
furniture plywood ends
(FPEB)
• Great for use on a cabinet that
will be exposed on both ends
but only needs a decorative
treatment on one side (e.g.,
cabinet flanking window with
a valance over the window and
is on the end of the run on the
other side)
• Field installed
• Furniture plywood ends option
flushes both sides of cabinet,
allowing replacement door to be
applied to either end
• Matches cabinet door reveal, top
and bottom for a uniform look
• Field installed
• Decorative panel and trim
molding can be used to match
a bead board cabinet door or
paneling on back of an island
• Field installed
When adding replacement doors to finish the ends of base/tall cabinets, also consider the following:
Use A Replacement Drawer Front
With A Smaller Door For A Uniform Look, Front And Side
Add A Piece Of Cove Base Board
Or Ogee Pilaster
Under The Door On The
Side For A Furniture Look
