E52
Base Accessories
Base Cabinets
Sink Base U-Shaped Deluxe Roll-out Tray-Field Installation
SBUDXROT36
SBUDXROT39
SBUDXROT42
• Roll-out trays are 4” deep, 3/4” solid wood
dovetailed sides with 3 1/6” plywood
bottom, notched front and full extension
runners with soft-close hinges
PE
APC
APFC
FPEB
MI
RD
WR
RTKP
VTK
4
4˝
21 / ˝
24 / ˝
27 / ˝
31 / ˝
34 / ˝
37 / ˝
4˝
New
Grey color coding indicates new product, size or code.
Sink Base Shallow Deluxe Roll-out Tray-Field Installation
SBDXROT36 •21
SBDXROT39 •21
SBDXROT42 •21
• Tray is nominally 21” deep to allow clearance
for plumbing
PE
APC
APFC
FPEB
MI
RD
WR
RTKP
VTK
New
Grey color coding indicates new product, size or code.
Base Blind Corner Wood Lazy Susan Kit
Specify R or L Blind
LSK42 R or L•WLS
LSK45 R or L•WLS
LSK48 R or L•WLS
• Available for 42”, 45” and 48” base blind
cabinets
• Kit includes two half circle shelves that rotate
out individually and mounting hardware
• Rotating shelves have plywood floor and
solid wood trim
• Right blind shown
• Field installation only
PE
APC
APFC
FPEB
MI
RD
WR
RTKP
VTK
Tray Dividers–Base
1TD
• 1/2” natural Birch Viraguard
• Available factory installed for 24” deep
cabinets only
• Installed in wood or plastic U-channels
• Shelves are eliminated when this option is
selected
• Specify quantity and location
• Order Example: B24R-2TD (spaced evenly)
•
Not
available in 40 1/2˝ high Base cabinets
PE
APC
APFC
FPEB
MI
l
RD
WR
RTKP
VTK
B24R-2TD shown
