E2
Base Cabinets
Base Cabinets
Base Single Door w/Deluxe Dovetailed Full-Width Tray(s)
Specify R or L
One tray, one adjustable shelf
B12 R or L•DXFWT
B15 R or L•DXFWT
B18 R or L•DXFWT
B21 R or L•DXFWT
B24 R or L•DXFWT
Specify R or L
Two trays, no shelf
B12 R or L•2DXFWT
B15 R or L•2DXFWT
B18 R or L•2DXFWT
B21 R or L•2DXFWT
B24 R or L•2DXFWT
• Adjustable, full-width
Roll-out Tray(s) (ROT)
• Roll-out Trays (ROT)
are 4” deep, 3/4˝ solid
wood dovetailed sides
with 3/16” plywood
bottom, notched front
and full extension
runners with integrated buffer
I
Reduced Depth (RD) available in 18˝
and 21˝ depths only
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
I
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
24˝
34
1
/
2
˝
•DXFWT
•2DXFWT
Base Single Door w/Full-Width Tray(s)
Specify R or L
One tray, one adjustable shelf
B12 R or L•FWT
B15 R or L•FWT
B18 R or L•FWT
B21 R or L•FWT
B24 R or L•FWT
Specify R or L
Two trays, no shelf
B12 R or L•2FWT
B15 R or L•2FWT
B18 R or L•2FWT
B21 R or L•2FWT
B24 R or L•2FWT
• Adjustable, full-width
Roll-out Tray(s) (ROT)
• Roll-out Trays (ROT)
cannot
be included
when a Reduced Depth
(RD) option of less than
18” is selected
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
l
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
•FWT
•2FWT
24˝
34
1
/
2
˝
Base Double Door w/Deluxe Dovetailed Full-Width Tray(s)
One tray,
one adjustable shelf
B24 BUTT•DXFWT
B27 (Butt)•DXFWT
s
B30 •DXFWT
B30 BUTT•DXFWT
s
B33 •DXFWT
B33 BUTT•DXFWT
s
B36 •DXFWT
B36 BUTT•DXFWT
Two trays,
no shelf
B24 BUTT•2DXFWT
B27 (Butt)•2DXFWT
s
B30 •2DXFWT
B30 BUTT•2DXFWT
s
B33 •2DXFWT
B33 BUTT•2DXFWT
s
B36 •2DXFWT
B36 BUTT•2DXFWT
• Adjustable, full-width
Roll-out Tray(s) (ROT)
• Roll-out Trays (ROT)
are 4” deep, 3/4˝ solid
wood dovetailed
sides with 3/16”
plywood bottom,
notched front and full
extension runners with integrated buffer
I
Reduced Depth (RD) available in 18˝ and
21˝ depths only
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
I
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
•2DXFWT
•DXFWT
24˝
34
1
/
2
˝
s
Mullion strip attached to left door
Base Double Door w/Full-Width Tray(s)
One tray, one adjustable shelf
B24 BUTT•FWT
B27 (Butt)•FWT
s
B30 •FWT
B30 BUTT•FWT
s
B33 •FWT
B33 BUTT•FWT
s
B36 •FWT
B36 BUTT•FWT
Two trays, no shelf
B24 BUTT•2FWT
B27 (Butt)•2FWT
s
B30 •2FWT
B30 BUTT•2FWT
s
B33 •2FWT
B33 BUTT•2FWT
s
B36 •2FWT
B36 BUTT•2FWT
• Adjustable, full-width
Roll-out Tray(s) (ROT)
• Roll-out Trays (ROT)
cannot
be included
when a Reduced Depth
(RD) option of less than
18” is selected
Remember,
when designing a space for
storing heavy items, avoid using
30–36” wide Roll-Out Trays (ROT). These
units are
not
designed for extremely
heavy loads
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
l
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
•FWT
•2FWT
24˝
34
1
/
2
˝
s
Mullion strip attached to left door
