Specifications and Options
C24
Construction Options
Mullion Strip Utility Top–Void Center Stile
MSUT
• On double door cabinets (30” or wider) the center
stile can be removed from the upper section of a tall
cabinet. When this is done, a mullion strip is attached
to the left door.
• Solid wood
• Painted hardwood supplied for EverCore™
• If Inverted Frame (IF) option is chosen with this option,
the smaller section, now on bottom, will have the
mullion strip
•
Not
available on cabinets with standard Mullion Strip
Base (MSB). Example: Multi-Storage Pantry (MSP),
Utility Roll-out Tray (U-ROT).
•
Not
available with butt door cabinets
• Example: U302484-MSUT
•
Note
: MSUB and MSUT
not
available on same cabinet
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Utility Bottom–Void Center Stile
MSUB
• On double door cabinets (30” or wider) the center
stile can be removed from the lower section of a tall
cabinet. When this is done, a mullion strip is attached
to the left door
• Solid wood
• Painted hardwood supplied for EverCore™
• If Inverted Frame (IF) option is chosen with this option,
the larger section, now on top, will have the mullion
strip
•
Not
available with butt door cabinets
• Example: U302484-MSUB
•
Note
: MSUB and MSUT
not
available on same cabinet
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Oven Cabinet–Void Center Stile
MSOTB
• On 33” and 39” wide single oven cabinets the center
stile can be removed from the upper and lower
sections. When this is done, a mullion strip is attached
to the left doors.
• Solid wood
•
Not
available with butt door cabinets
• Example: OC332484S-MSOTB
• Painted hardwood supplied for EverCore™
•
Note
: This option applies only to the OC 33_S and OC
39_S cabinets
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Top Wide Rail
TWRB
Both Sides
TWRK
Kitchen Side
TWRP
Peninsula Side
• We offer many base and vanity cabinets with a Top
Wide Rail option. Consult option availability chart for
your desired cabinet.
• No drawer or drawer front
• Quartersawn door styles have quartersawn top wide
rail, cabinet frame is plain sawn wood
• Painted hardwood supplied for EverCore™
• When TWRP is selected, the drawer box will be three
inches shallower than the standard drawer box. See
illustration.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
* e reveal on a cabinet with TWR varies
depending on the door overlay. See chart.
8˝*
Peninsula side
Kitchen side
Overlay 1/2˝ Full
Reveal
7 ½ ˝ 6 ⅞ ˝
