Replacement Parts
N3
Whisper Touch™ Drawer Clips
BOX •BWTDC
• Box of ten, five left and five right
PBWTDC
• Packaged and sold as a pair
PBWTDC •S
• Packaged and sold as a pair
• Used for:
BLB — Base Liter Bottle
BPP — Base Pantry Pull-out
VBP — Vanity Base Pull-out
VSB36.2D — Vanity Sink Base
Whisper Touch™ Angle Restrictor Clip
WTHARC
• Limits hinge opening angle to 86 degrees (+/- 2 degrees)
•
Cannot
be used in cabinets with installed accessories
• Used for:
PH1516•SC — Whisper Touch™ Hinges - Full Overlay
PH12C•SC — Whisper Touch™ Hinges - Half Overlay
PHFM•SC — Whisper Touch™ Hinges - Face Mount
• Packaged and sold four per box
•
Note
: One clip per door is sufficient; however, one clip
per hinge results in less deflection
Whisper Touch™ Deluxe Dovetailed Roll-Out Tray Drawer Runners
PBWTDXR18
PBWTDXR21
PBWTDXR24
• 90 lb. capacity
• Fully concealed
• Full extension runner, pulls out past the face frame
• Ball bearing operation
• Integrated mechanism closes drawers softly and quietly
• Packaged and sold as a pair
•
Must
order drawer clips separately
Whisper Touch™ Deluxe Dovetailed Roll-Out Tray Mounting Block Kit
BWTDXROTK
• Includes mounting blocks, drawer glide mounting
sleeves and fasteners
• Used for:
Whisper Touch™ Deluxe Dovetailed Roll-out Tray
runners
• Packaged and sold as a pair
