Decorative Enhancements
M2
LED Lighting
LED Puck Light
LED•PCK1
• One light with 8’ power cable; 2.4W
• Warm white illumination
• 12 degree directional swivel
• 144 lumens; 70 degree beam angle
• For surface mount or recess installation
• Units are 2 9/16” diameter. Requires 2 1/4”
diameter circle cut out for recess installation
• Use 8’ power extension cables (LED•PEC8) to
extend the distance between lights and power
supply
Under Cabinet Panel (PUCP, UCP
OR UCPWA) provides a clean, built-
in look for under cabinet installation
LED 3 Puck Light Kit
LED•PCK3•KIT
• Kit includes: (3) LED Puck Lights (LED•PCK1)
(1) DayBreak Dimmable Driver 18W (LED•DDR18)
(2) 8’ Power Extension Cables (LED•PEC8)
8’ Power Cable
LED•PC
• Cable has male connector on one end and
flexible strip connector on the other
• Used to start the flexible strip light run
8’ Power Extension Cable
LED•PEC8
• Cable has male connector on one end and
female connector on the other
• Used to extend the distance between the
power supply and the light source
• Several cables may be connected to extend
the length if needed
Connector Kit for Custom Wire Length
LED•CLC
• Contains two connectors
• For use when adding a cut-to-length wire
section to navigate LED Flexible Strip Tape
Light (LED•TPL or LED•TPLSP) around corners
or obstacles
LED Connectors
