Decorative Enhancements
M1
LED Lighting
LED Lighting
Construction Options and Modifications
LED is an energy efficient source for kitchen and bath lighting needs.
Puck and strip lights have 3000K light color. All products are 24V DC power.
All wires are white.
Each LED light is tested at 50,000 hours of run time. 2 year limited warranty on
LED light source, wires and connectors. 5 year limited warranty on power supply.
For limited warranty details, see
.
See
for instructional videos on designing and installing lighting.
Specifications subject to change without notice.
LED
code
LED Flexible Strip Tape Light
LED Flexible Strip Tape Light
LED•TPL
LED Flexible Strip Splash Proof Tape Light
LED•TPLSP
• Standard LED flexible strip tape with self adhesive
backing
• 16.4’ long; 0.32” wide; ~0.15” tall; 300 diodes; 18W
• Warm white illumination
• 120 degree beam angle, 84 lumens per foot
• A power cable (LED.PC) is required to connect strip
tape lighting to a power supply. Strip tape lengths
cannot
exceed 16.4’ out of a single power supply port.
An additional power cable (LED.PC) plugged into an
unused power supply port is required for applications
exceeding 16.4’. Make sure power supplies are
not
overloaded based on watt capacity. See “LED Power
Supply” section for capacity details
• For use under-cabinet, over-cabinet, toe kick and
cabinet interiors
• Use LED•TPLSP for splash zones i.e. toe-kick space
• Custom lengths can be cut in increments of 2”,
not
to exceed a total of 16.4’. Use End-to-End Connector
(LED•ETEC) to join custom lengths
• Use Connector Kit for Custom Wire Length (LED•CLC)
with Standard Copper Wire (LED•SCW25) to navigate
corners or other obstacles
• Use Motion Sensor Switch (LED•MSS) for controlling
interior cabinet lighting
• Use 8’ Power Extension Cables (LED•PEC8) to increase
distance between power supply and beginning of LED
flexible strip run
Installers
must
clean and prepare surface
prior to installation. An alcohol pad works
well to remove oils
LED•TPL
LED•TPLSP
LED Flexible Strip Tape Light Kit
LED•TPL•KIT
• Kit includes: (1) LED Flexible Strip Tape Light (LED•TPL)
(1) DayBreak Dimmable Driver 18W (LED•DDR18)
(2) 8’ Power Cables (LED•PC)
(2) 8’ Power Extension Cables (LED•PEC8)
(2) End-to-End Connectors (LED•ETEC)
(3) Connector Kits for Wire Length (LED•CLC)
(1) Stranded Copper Wire (LED•SCW25)
LED Light Sources
