Furniture Cabinets
I23
Wood Tops
Angled Wood Top
48” Wide
AWT1348
AWT2248
AWT2548
AWT3248
96” Wide
AWT1396
AWT2296
AWT2596
AWT3296
Peninsula
48” Wide
PAWT1348
PAWT2248
PAWT2548
PAWT3248
96” Wide
PAWT1396
PAWT2296
PAWT2596
PAWT3296
• Finished dimensions and finished edges
must
be specified. Finished dimensions are available
in 1/16˝ increments only.
• Tops will be supplied for straight applications
only including peninsula and islands with up
to four finished edges
• Wood tops are built to size
•
Not
available in Morristown; Brockton,
Melrose and Putnam Oak supplied plain sawn
• Painted hardwood supplied for EverCore™ and
Laminate
•
Note
: Heavy lines indicate finished edges
l
APC
13˝, 22˝
25˝, 32˝
1
9
/
16
˝
49
/
64
˝
5
/
8
˝
Wood Veneer
Build-up
Strip
Single Bead Wood Tops
48” Wide
SBWT1348 •M
SBWT2248 •M
SBWT2548 •M
SBWT3248 •M
96” Wide
SBWT1396 •M
SBWT2296 •M
SBWT2596 •M
SBWT3296 •M
Peninsula
48” Wide
PSBWT1348 •M
PSBWT2248 •M
PSBWT2548 •M
PSBWT3248 •M
96” Wide
PSBWT1396 •M
PSBWT2296 •M
PSBWT2596 •M
PSBWT3296 •M
• Finished dimensions and finished edges
must
be specified. Finished dimensions are available
in 1/16˝ increments only.
• Tops will be supplied for straight applications
only including peninsula and islands with up
to four finished edges
• Wood tops are built to size
• Available in quartersawn Oak door styles only
•
Note
: Heavy lines indicate finished edges
l
APC
3
/
4
˝
5
/
8
˝
1
9
/
16
˝
13˝, 22˝
25˝, 32˝
Wood Veneer
Build-up
Strip
Clipped Corner Wood Tops
CCB
Clipped Corner Both
CCL
Clipped Corner Left
CCR
Clipped Corner Right
• 45° clipped corners
• Finished Ends supplied when Clipped Corner
option is specified
• Painted hardwood supplied for EverCore™
•
Note
: Heavy lines indicate finished edges
APC
¾˝
TWT2296-CCR
TWT2296-CCL
TWT2296-CCB
PTWT2296-CCR
PTWT2296-CCL
PTWT2296-CCB
Finished End Wood Tops
FEB
Finished End Both
FEL
Finished End Left
FER
Finished End Right
• Edge molding is miter cut at 90° corners
• Painted hardwood supplied for EverCore™
•
Note
: Heavy lines indicate finished edges
APC
TWT2296-FER
TWT2296
TWT2296-FEL
TWT2296-FEB
PTWT2296-FER
PTWT2296
PTWT2296-FEL
PTWT2296-FEB
