Wall Cabinets
D83
Wall Specialty Cabinets
Wall Filler Pull-out
Three adjustable shelves
30” High
WFP3•30
2 1/8” shelf width
WFP6•30
5 1/8” shelf width
33” High
WFP3•33
2 1/8” shelf width
WFP6•33
5 1/8” shelf width
Four adjustable shelves
36” High
WFP3•36
2 1/8” shelf width
WFP6•36
5 1/8” shelf width
39” High
WFP3•39
2 1/8” shelf width
WFP6•39
5 1/8” shelf width
Five adjustable shelves
42” High
WFP3•42
2 1/8” shelf width
WFP6•42
5 1/8” shelf width
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
• Unit slides on full extension side-mount
runners
• Recommended installation is between two
cabinets
• Installation may also be made between a
cabinet and a wall or a cabinet and an end
panel with stile
• Filler is included, but unattached. Unit
should be installed before removing shipping
brace and attaching filler
• A filler overlay is recommended for full overlay
door styles;
must
be ordered separately
Do
not
use filler pullouts (WFP,
WSPP, BFP, BSPP) at the end of
cabinet runs or next to appliances.
They
must
be installed between two cabinets
or a cabinet and an end panel.
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
TWR
XS
GD
30˝
33˝
36˝
39˝
42˝
Install decorative hardware
prior to attaching filler
to pull-out unit
Side View
Filler
Filler
11 / ˝
Gray color coding indicates new product, size or code.
Wall Pantry Pull-out
30” High
i
WPP930
WPP1230
33” High
i
WPP933
WPP1233
36” High
i
WPP936
WPP1236
39” High
i
WPP939
WPP1239
42” High
;i
WPP942
;
WPP1242
• Three adjustable shelves
• Shelves have solid wood floor with chrome
wire side rails
• Shelves are 9 1/2˝ deep
• Shelf widths are 4 1/4˝ or 7 1/8˝
• Unit slides on full extension side-mount
runners
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
RD
ID
CH
TWR
l
XS
GD
39˝
42˝
12˝
12˝
30˝
12˝
33˝
12˝
36˝
12˝
i
Doors are square except full overlay arch
door styles. Laminate door styles will always
be square. Harlowe, Smithton and Vanderbilt
doors will have a solid, recessed flat panel.
;
One adjustable shelf above pull-out
Gray color coding indicates new product, size or code.
Wall Pantry Pull-out Stack
48” High
i;
WPPST948 R or L
WPPST1248 R or L
51” High
i;
WPPST951 R or L
WPPST1251 R or L
54” High
i;
WPPST954 R or L
WPPST1254 R or L
• Two vertical compartments with fixed rail
and floor
• Available in full overlay door styles only
• Bottom door is always square
I
Glass doors available for top doors only
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
CW
RD
ID
CH
TWR
XS
I
GD
54˝
48˝
51˝
12˝
12˝
i
Doors are square except full overlay arch
door styles. Laminate door styles will always
be square. Harlowe, Smithton and Vanderbilt
doors will have a solid, recessed flat panel.
;
Glass door option
not
available
Gray color coding indicates new product, size or code.
