In this project, we will show how to build a simple LED flasher circuit using a 555 timer chip.
An LED flasher circuit is a circuit which flashes the LED- meaning turns it ON-OFF, ON-OFF, ON-OFF. The rate that the LED flashes is determined by the resistors R1 and R2 and the electrolytic capacitor C1. According to the above formulas, the larger value we use for the resistors and the capacitor, the longer the cycle will be.


However, on the other extreme, we do not want to choose values which are too small as well. These values for resistors R1 and R2 and capacitor C1 allows us to see the flashing of the LED.
We need all the parts listed for the first circuit, now with the addition of 1 more 1K? resistor and 1 red LED.
This is why this mode is also called oscillator mode, because it uses the 555 timer an oscillator, which creates square wave signals.
