M25
Molding
Note
: Heavy, dark lines indicate finished surfaces.
Decorative Enhancements
Corner Tall Molding
CTM8
• Solid wood
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Maple supplied for Birch
• Oak supplied for Hickory
• Quartersawn door styles will be supplied in plain
sawn wood
• See Option #2 in Diagonal Installation of Standard
Tall Cabinets in the back of the Tall Cabinets section
• Corner Tall End Panel (CTEP) and Corner Tall Molding
(CTM8) are sold separately
•
Note
: For use with WCTEP 84 or 96 only; will
not
work with WTEP
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
CTM8
WCTEP84
Tall cabinet
installed at
a 45° angle
8´
2
5
/
32
˝
3
/
16
˝
25
/
32
˝
Transition Molding
Modern
TRM8
Traditional
TTRM8
• Solid wood
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Quartersawn door styles will be supplied in plain
sawn wood
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8'
TTRM8
Traditonal
TRM8
Modern
8'
/ ˝
/ ˝
/ ˝ / ˝
1 / ˝
1 / ˝
/ ˝
¾˝
¾˝
¼˝
Cabinet face
frame
Cabinet face
frame
1/2" end panel
3/8" skin
TRM8
3/4" end panel
3/16" skin
TRM8
Top View
Wall Cabinet Floor
Wood Block
WSK
Cabinet Door
TRM8
Cabinet Face Frame
Side view of Wall Cabinet application. Use
additional TRM8 or SM8 where cabinet meets wall.
Side View
Allows a 3/16˝ skin to be applied
to a cabinet with 3/4˝ end panels
Allows a 3/8˝ skin to be applied
to a cabinet with 1/2˝ end panels
Solid Stock
I
S3S1
I
S3S3
S3S6
• Solid wood
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Use solid stock material as finished nailing strip for
molding applications
• When ordered in Burnished, Distressed or Vintage
finishes, solid stock will receive applicable finish
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8´
1
1
/
2
˝
3˝
6˝
¾˝
I
Quartersawn door styles will be
supplied in plain sawn wood
Library Molding
LM8
• Solid wood
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Quartersawn door styles will be supplied in plain
sawn wood
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8´
2
9
/
16
˝
1
9
/
16
˝
1
/
4
˝
1
/
4
˝
3
/
4
˝
9
/
16
˝
