M13
Molding
Note
: Heavy, dark lines indicate finished surfaces.
Decorative Enhancements
Classic Crown Molding
CCM8 •NG
CCM10 •NG
• Solid wood
• Foil-wrapped MDF supplied for White Laminate
• Painted hardwood supplied for EverCore™, Cream
Laminate and 10’ molding
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Quartersawn door styles will be supplied in plain sawn
wood
• Will have rustic characteristics when ordered in rustic
door styles.
Use
caution
when applying Classic Crown
Molding (CCM8), Crown Molding (CM8),
etc., when ”stair stepping” wall cabinets in full overlay
door styles otherwise the doors may hit the molding
while opening.
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
2
7
/
16
˝
3
5
/
16
˝
4
1
/
8
˝
3
/
4
˝
8´,10´
Classic Crown Molding w/Molding Mounting Strip
CCM8 •MS
CCM10 •MS
• Solid wood
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Quartersawn door styles will be supplied in plain sawn
wood
• Will have rustic characteristics when ordered in rustic
door styles.
• Mounting strip may be installed first, allowing for
easier alignment and quicker installation of grooved moldings
• Shipped as two pieces
v
A
v
B
v
C
v
E
v
H
L
LHG
v
LWG
v
M
v
O
v
QS
3
5
/
16
˝
2
7
/
16
˝
4
1
/
8
˝
3
/
4
˝
1 ¼˝
¾˝
8´,10´
Sterling Crown Molding
Large
LSTCM8
Extra Large
XLSTCM8
• Solid wood
• Painted hardwood supplied for EverCore™ and
Laminate
I
Painted hardwood supplied for Woodgrain Laminate
door styles; only available in white
The Sterling Collection design combines
automated wood-machining processes with
hand detailing. Because of the hand
detailing, slight imperfection and/or differences may
exist from part to part and are normal. These do
not
affect the structural performance of the product but
enhance the aesthetics of each piece.
v
A
B
v
C
v
E
H
v
L
LHG
I
LWG
v
M
O
QS
8´
8´
2 ½˝
2 / ˝
4 ½˝
LSTCM
XLSTCM
3 / ˝
Cove Molding
Small
SCVM8 •NG
SCVM10 •NG
Large
LCVM8 •NG
LCVM10 •NG
Extra Large
XLCVM8 •NG
XLCVM10 •NG
• Solid wood
• Painted hardwood supplied for EverCore™, Cream
Laminate and 10’ molding, except for Small Cove
Molding (SCVM8) and Large Cove Molding (LCVM8),
which will have foil-wrapped MDF supplied for White
Laminate
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
• Quartersawn door styles will be supplied in plain
sawn wood
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
2˝
1
8´,10´
SCVM •NG
2
2
8´,10´
LCVM •NG
3 / ˝
4
XLCVM •NG
½˝
½˝
/ ˝
8´,10´
/ ˝
