G24
Vanity Cabinets
Vanity Cabinets
Vanity Utility Cabinet 21” Deep w/Deluxe Dovetailed Roll-out Tray
Specify R or L
84” High
VU152184 R or L•4DXROT
VU182184 R or L•4DXROT
VU212184 R or L•4DXROT
VU242184 R or L•4DXROT
m
VU242184 BUTT•4DXROT
VU272184 (Butt)•4DXROT
VU302184 BUTT•4DXROT
VU332184 BUTT•4DXROT
VU362184 BUTT•4DXROT
87” High
VU152187 R or L•4DXROT
VU182187 R or L•4DXROT
VU212187 R or L•4DXROT
VU242187 R or L•4DXROT
m
VU242187 BUTT•4DXROT
VU272187 (Butt)•4DXROT
VU302187 BUTT•4DXROT
VU332187 BUTT•4DXROT
VU362187 BUTT•4DXROT
90” High
VU152190 R or L•4DXROT
VU182190 R or L•4DXROT
VU212190 R or L•4DXROT
VU242190 R or L•4DXROT
m
VU242190 BUTT•4DXROT
VU272190 (Butt)•4DXROT
VU302190 BUTT•4DXROT
VU332190 BUTT•4DXROT
VU362190 BUTT•4DXROT
93” High
VU152193 R or L•4DXROT
VU182193 R or L•4DXROT
VU212193 R or L•4DXROT
VU242193 R or L•4DXROT
mr
VU242193 BUTT•4DXROT
VU272193 (Butt)•4DXROT
VU302193 BUTT•4DXROT
VU332193 BUTT•4DXROT
VU362193 BUTT•4DXROT
96” High
VU152196 R or L•4DXROT
VU182196 R or L•4DXROT
VU212196 R or L•4DXROT
VU242196 R or L•4DXROT
m
VU242196 BUTT•4DXROT
VU272196 (Butt)•4DXROT
VU302196 BUTT•4DXROT
VU332196 BUTT•4DXROT
VU362196 BUTT•4DXROT
• Four adjustable Roll-out Trays (ROT)
included in lower section
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Roll-out Trays (ROT) shipped separately on
27˝–36˝ wide units
• Roll-out Trays (ROT)
cannot
be included
when a Reduced Depth (RD) option of less
than 18” is selected
• 27˝–36˝ wide units
not
available with
Reduced Depth (RD)
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
I
When Inverted Frame (IF) is chosen in arched
door styles, VU18, VU24, VU24BUTT and
VU36 cabinets will have arched doors. All
other cabinet sizes will be supplied with
square doors
I
WR and RTK
not
available on 93” & 96” high cabinets
I
Glass doors available for top doors only
I
VTK is
not
available on 93” and 96” high cabinets
•
Not
available in Halden door styles
Remember to remove the white plastic ”feet”
from the bottom of all tall cabinets before
installation. Their sole purpose is to protect
the floor after the cabinets are unboxed. Leaving them
on will result in an uneven installation.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
I
CW
l
RD
l
ID
l
CH
I
IF
TWR
I
WR
l
XS
I
GD
I
RTK
I
VTK
VU15-24
VU24-36
21˝
21˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
New
m
Change Width (CW) option
not
available
Grey color coding indicates new product, size or code.
Vanity Wall Cabinet
Specify R or L
4 5/8” Deep
30” High
VW120430 R or L
VW150430 R or L
m
VW240430
VW270430
36” High
VW120436 R or L
VW150436 R or L
m
VW240436
VW270436
8” Deep
30” High
VW120830 R or L
VW150830 R or L
m
VW240830
VW270830
36” High
VW120836 R or L
VW150836 R or L
m
VW240836
VW270836
• Specify R or L for single door hinging
• Three adjustable 1/2˝ thick shelves
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
I
CW
RD
ID
l
CH
IF
TWR
WR
l
XS
l
GD
RTK
VTK
30˝
36˝
4 / ˝, 8˝
4 / ˝, 8˝
m
Change Width (CW) option
not
available
