F29
Tall Cabinet Accessories
Tall Cabinets
Refrigerator End Panel w/Stile
32” Deep
84” High
DREP1 1/2•84
DREP3•84
87” High
DREP1 1/2•87
DREP3•87
90” High
DREP1 1/2•90
DREP3•90
93” High
DREP1 1/2•93
DREP3•93
96” High
DREP1 1/2•96
DREP3•96
108” High
I
DREP1 1/2•108
I
DREP3•108
120” High
I
DREP1 1/2•120
I
DREP3•120
24” Deep
84” High
REP1 1/2•84
REP3•84
87” High
REP1 1/2•87
REP3•87
90” High
REP1 1/2•90
REP3•90
93” High
REP1 1/2•93
REP3•93
96” High
REP1 1/2•96
REP3•96
108” High
I
REP1 1/2•108
I
REP3•108
120” High
I
REP1 1/2•120
I
REP3•120
• Reversible
• Exterior finished to match, interior is Natural
Birch Viraguard
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
l
PE
l
APC
I
APFC
l
FPEB
I
MI
CW
l
RD
ID
l
CH
WR
24˝, 32˝
84˝
87˝
90˝
93˝
96˝
108˝
120˝
I
Matching Interior All Plywood Furniture
Construction (MIAPFC) standard on these sizes
only
Sub Zero End Panel
Viraguard
24” Deep
sn
VZEP84
Wood Veneer
24” Deep
i
$
WZEP84
• Reversible
• Panel notched to accept Sub Zero trim kit
I
APC panel only available in wood veneer
I
Maximum Increased Depth (ID) is 27”
Be sure to verify panel and
appliance model compatibility
PE
I
APC
APFC
FPEB
MI
CW
l
RD
I
ID
CH
WR
84˝
24˝
2
1
/
2
˝
1
/
2
˝
3
/
8
˝
s
Not
available in Alder–Rustic door styles
n
Not
available in Morristown; Melrose and Putnam
supplied plain sawn
i
Painted hardwood supplied for EverCore™ and
Laminate
$
Quartersawn door styles will be supplied in plain
sawn wood
Matching Tall End Panel
Specify R or L
60 1/2” High
MTEP1260 R or L
MTEP2460 R or L
84” High
MTEP1284 R or L
MTEP2484 R or L
87” High
MTEP1287 R or L
MTEP2487 R or L
90” High
MTEP1290 R or L
MTEP2490 R or L
93” High
MTEP1293 R or L
MTEP2493 R or L
96” High
MTEP1296 R or L
MTEP2496 R or L
• 3/4” thick panel with matching door edge
profile on front edge only
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Left shown
• Field installation only
•
Not
available in Morristown
•
Not
available in High-Gloss Laminate,
Laminate or Woodgrain Laminate door styles
•
Not
available in mitered door styles; use End
Panel–Mitered
•
Not
available in slab door styles
I
Wide Bottom Rail—field notch for toe kick
When designing with Matching End Panels the
reveal will differ from the cabinet door height
reveal. Matching End Panels cover the entire side
of the cabinet. See drawing for exact
measurements
PE
APC
APFC
FPEB
MI
CW
RD
ID
CH
I
WR
Standard edge detail—fits flush against
1/2˝ end panel and behind face frame
11 / ˝
23 / ˝
11 / ˝
¾˝
23 / ˝
60
1
/
2
˝
84˝
87˝
90˝
93˝
96˝
/ ˝
