SB36•2D1U - SB42•2D1U
SB36•2D2U - SB42•2D2U
34 ½˝
34 ½˝
4˝
4˝
21 / ˝
24 / ˝
27 / ˝
31 / ˝
34 / ˝
37 / ˝
4˝
5 / ˝
Drawer content
height clearance
10 ¾˝
Sink height
allowance
8 / ˝
6˝
E12
Base Cabinets
Base Cabinets
Sink Base–Clipped and Fluted Clipped Corners
Clipped Corners
SBCC3027 BUTT
SBCC3327 BUTT
SBCC3627 BUTT
SBCC4227 BUTT
Fluted Clipped Corners
s
SBFCC3027 BUTT
s
SBFCC3327 BUTT
s
SBFCC3627 BUTT
s
SBFCC4227 BUTT
• No shelf
• False drawer front
• Optional Door Storage
Unit (SBDSU) is available
• Optional Utensil Trays (UT
and SUT) are available
• Angled stiles extend 3˝
each side
• Nominal width is overall
cabinet width. Order
Example: SBCC3027BUTT
is 30˝ wide
• Factory installed Roll-out Trays (ROT) are
not
available
• Can be used as corner sink by butting up
adjacent cabinets to the clipped corner area
• Includes a Touch-Up Kit (TUK)
• Use Full-Height Kitchen (FHK) option to
achieve a full-height door look
I
Minimum Reduced Depth (RD) is 15˝
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
OE
CW
I
RD
CH
IF
l
TWR
WR
XS
XSG
l
GD
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
27˝
SBCC
SBFCC
34
1
/
2
˝
24˝
27˝
s
Not
available in Morristown; Melrose and
Putnam supplied plain sawn
Sink Base Multi-Storage Cabinet
SBMS30 BUTT
SBMS33 BUTT
SBMS36 BUTT
u
SBMS39
u
SBMS42
With Stainless Utensil Tray
SBMS30 BUTT•SUT
SBMS33 BUTT•SUT
SBMS36 BUTT•SUT
u
SBMS39 •SUT
u
SBMS42 •SUT
• No shelf
• False drawer front(s)
• Includes two Door
Storage Units (SBDSU)
and one Multi-Storage
Shelf (SBMSSK)
• Sink Base Multi-Storage
Shelf Kit (SBMSSK)
shipped separately
I
Sink Base Multi-Storage Shelf Kit (SBMSSK)
is Natural Birch plywood and does
not
come
matching
• Includes a Touch-Up Kit (TUK)
l
PE
l
APC
l
APFC
l
FPEB
I
MI
l
DE
OE
CW
RD
CH
IF
l
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
34
1
/
2
˝
24˝
34
1
/
2
˝
24˝
•SUT
u
3” center stile
Sink Base Drawer
One “U” shaped Drawer,
one full width Drawer
SB36 •2D1U
SB39 •2D1U
SB42 •2D1U
Two “U” shaped
Drawers
SB36 •2D2U
SB39 •2D2U
SB42 •2D2U
• “U” shaped drawers
are 7” to 4” scoop, 24”
deep
• Full width drawer is
7” high, 21” deep (
Not
“U” shaped)
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
CW
RD
CH
IF
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
New
Grey color coding indicates new product, size or code.
Deep Sink Base
DSB30 BUTT
DSB33 BUTT
DSB36 BUTT
DSB39 BUTT
DSB42 BUTT
• 3˝ stiles are routed to
1 1/2˝ in the door area
• Includes a Touch-Up Kit
(TUK)
•
Note:
Be sure to
follow manufacturer’s
specifications to ensure
proper sink fit
To avoid cutting the side walls of a
sink base cabinet, make sure your sink
base cabinet is at least 2 1/2” wider
than the overall width of your sink. If your
overall front-to-back sink depth is 22 1/2” or
greater use a 27” deep sink base.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
l
CW
l
RD
CH
IF
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
34 ½˝
5 ½˝
8¾˝
max
cutout
5˝
3˝
3˝
24˝
Grey color coding indicates new product, size or code.
