D63
Wall Cabinets
Wall Accessories
Matching Wall End Panel
Specify R or L
MWEP12 R or L
MWEP15 R or L
MWEP18 R or L
MWEP24 R or L
MWEP30 R or L
MWEP33 R or L
MWEP36 R or L
MWEP39 R or L
MWEP42 R or L
s
MWEP48 R or L
s
MWEP54 R or L
Double Panel & Stack
s
%
u=
MWEPDP54 R or L
Peninsula
%
PMWEP12
%
PMWEP15
%
PMWEP18
%
PMWEP24
%
PMWEP30
%
PMWEP33
%
PMWEP36
%
PMWEP39
%
PMWEP42
• 3/4” thick
• Inside of matching panel bottom
rail will line up with inside bottom
rail of door
• Left shown
• Field installation only
• Laminate, mitered and slab door
styles do
not
have grooves and will
not
fit flush against 1/2” end panel.
A 3/16” shim is recommended
• Peninsula panel has routed door
profile front and back
•
Not
available in High-Gloss
Laminate door styles
•
Not
available in Morristown
When designing with Matching End
Panels the reveal will differ from the
cabinet door height reveal. Matching
End Panels cover the entire side of the
cabinet. See drawing for exact measurements
PE
APC
APFC
FPEB
MI
CW
RD
ID
CH
XS
GD
11 / ˝
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
¾˝
/ ˝
54˝
11 / ˝
MWEPDP54
s
Available in full overlay door styles only
%
Not
available in Woodgrain Laminate door styles
u
Not
available in mitered door styles
=
Not
available in slab door styles
Matching Wall End Panel–Square Edges
MWEP12 S
MWEP15 S
MWEP18 S
MWEP24 S
MWEP30 S
MWEP33 S
MWEP36 S
MWEP39 S
MWEP42 S
s
MWEP48 S
s
MWEP54 S
• 3/4˝ thick panel with square edge
front and back
• Inside of matching panel bottom
rail will line up with inside bottom
rail of door
• Reversible, may be used on either
right or left end
• Field installation only
• No frame recess dado
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in mitered door styles
•
Not
available in Morristown
PE
APC
APFC
FPEB
MI
CW
RD
ID
CH
XS
GD
11 / ˝
Will not fit flush against ½˝ end
panel; a ⁄
˝ shim is recommended
54˝
11 / ˝
MWEPDP54S
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
s
Available in full overlay door styles only
u
Not
available in slab door styles
Furniture Matching Wall End Panel
Specify R or L
FMWEP12 R or L
FMWEP15 R or L
FMWEP18 R or L
FMWEP24 R or L
FMWEP30 R or L
FMWEP33 R or L
FMWEP36 R or L
FMWEP39 R or L
FMWEP42 R or L
s
FMWEP48 R or L
s
FMWEP54 R or L
Double Panel & Stack
su=
FMWEPDP54 R or L
Peninsula
FPMWEP12
FPMWEP15
FPMWEP18
FPMWEP24
FPMWEP30
FPMWEP33
FPMWEP36
FPMWEP39
FPMWEP42
• 3/4” thick
• Inside of matching panel bottom
rail will line up with inside bottom
rail of door
• Left shown
• Field installation only
• Peninsula panel has routed door
profile front and back
• For use with Furniture Plywood
Ends (FPEB)—flush ends
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Morristown
PE
APC
APFC
FPEB
MI
CW
RD
ID
CH
XS
GD
11 / ˝
54˝
11 / ˝
FMWEPDP54
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
s
Available in full overlay door styles only
u
Not
available in mitered door styles
=
Not
available in slab door styles
Overlay Panel For Wall Blind Corner Cabinets
OPWBC24
OPWBC30
OPWBC33
OPWBC36
OPWBC39
OPWBC42
OPWBC48
OPWBC54
• Available in full overlay door styles
only
• Overlay Panel has routed door
profile and is made from the same
material as doors and drawer
fronts
• Field miter
PE
APC
APFC
FPEB
MI
CW
RD
ID
CH
XS
GD
9˝
23 / ˝
29 / ˝
32 / ˝
35 / ˝
38 / ˝
41 / ˝
47 / ˝
53 / ˝
Double Panel & Stack
su
MWEPDP54 S
