Cabinet Specs
Material dimensions listed may vary slightly from actual dimensions of the product
Specifications and Options
Cabinet Specifications
• (1) Viraguard clad back panel
• (2) 1/2” wood concealed hanging rail
• (3) 1/2” Natural Birch Viraguard clad ceiling panel
• (4) 3/4˝ solid hardwood, including but not limited
to, Alder, Birch, Cherry, Hickory, Maple and Oak
front frame constructed using industrial grade glue
and hardened steel fasteners. Front frame species
complements selected door style.
• (5) Extensive and unique door style and wood
species selection in Alder, Birch, Cherry, EverCore™,
Hickory, Maple and Oak. Solid and wood veneer
construction available. Also available in Laminate,
High-gloss Laminate and Woodgrain Laminate.
• (6) Satin chrome shelf rests for all kitchen wall and
furniture cabinets. Easily adjustable positive locking
shelf clips for all base, tall and vanity cabinets.
• (7) Natural Birch Viraguard interior.
• (8) 3/4” fully adjustable Natural Birch Viraguard
clad shelving standard feature in wall, base and tall
cabinets.
• (9) 1/2” Natural Birch Viraguard clad cabinet bottom
• (10) 14-step DuraKraft Plus™ furniture process
featuring hand-wiped stain with one of the finest
wood finishes available in the cabinet industry
• (11) Full-depth I-beam braces provide stability and
convenient anchor points for countertop
• (12) 3/8” Natural Birch Viraguard clad base back
panel
• (13) 3/4” solid wood base installation rail
• (14) Standard drawer runner suspension system
features smooth, ball bearing operation with a 90
lb. load capacity. Whisper Touch™ runner has an
integrated drawer buffer that engages two inches
from closing and applies resistance, giving a soft,
controlled closing.
• (15) 3/4” full-depth solid wood dovetailed drawer
featuring four sided construction and 3/16” plywood
bottom
• (16) Self-closing, concealed, wrap-around adjustable
or optional knife hinges (KH)
• (17) Full-depth, fully adjustable 3/4” Natural Birch
Viraguard clad shelving
• (18) Drawer heads are solid hardwood or laminate to
complement each door style.
• (19) Fully closed toe space area.
• (20) 1/2˝ end panels with woodgrain Viraguard
interior and matching exterior. Also available
with optional 1/2˝ or 3/4˝ plywood end panels.
Woodgrain Viraguard interior or wood veneer
interior available. Unless noted, plain sawn end
panels will be supplied for quartersawn door styles.
• (21) Standard drawer boxes are 4 1/2” high
• Viraguard is the tradename of our printed wood
grain laminate
•
Note
: Unless noted, cabinet depth does
not
include
doors or drawer fronts
•
Note
: Please contact Customer Care if your design
requires verification of product specifications
8
7
3
2
1
4
10
9
5
6
12
14
20
21
13
15
19
17
11
18
6
16
Concealed Hinge
Knife Hinge
See Construction Options section for a complete description.
90 pound load capacity
Also available in an All Plywood (APC) Option
