Universal Design Cabinets
J7
Universal Cabinets
Universal Sink Front Kit
USFCK30 BUTT•FH
USFCK33 BUTT•FH
USFCK36 BUTT•FH
USFCK42 •FH
• Full-height door
• Toe Kick Backer assembly shipped
unassembled to floor
• Includes floor
• 3/8” thick engineered wood bottom panel
with easy clean laminate on one side; back
side unfinished
• 1/2” thick engineered wood toeboard
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
4ROT
1FWROT
2FWROT
2DROT
4DROT
2DFWROT
CFO
32 ½˝
24˝
Universal Removable Sink Front
URSF30 BUTT
URSF33 BUTT
URSF36 BUTT
URSF42
• Designed for easy field conversion from
a standard sink base functionality to
universal access open space
• Permanently installed countertop support
rail is 3-1/2” high x 3/4” thick solid wood
• Doors and frame are shipped pre-
assembled
• 3/4” thick removable plywood bottom
panel with support hardware / leveling
legs and a removable clipped-on toe kick
provided
• Matching solid wood baseboard provided
for bottom panel support along the
kitchen wall
• Frame attached to bottom panel using quick
connect (cam-locks) fasteners providing a
solid tight joint
• Some field assembly required; instructions and
hardware included
• A Universal Access Panel (UAP) can be
purchased separately to conceal/protect the
water and drain lines. See “Panels” section.
Please specify specie and finish
I
Regardless of construction option, sink front is
constructed and shipped the same
Complete flooring under Universal
Access Removable Sink Front to
prepare for the future when sink
front and plywood bottom is removed.
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
4ROT
1FWROT
2FWROT
2DROT
4DROT
2DFWROT
CFO
32 ½˝
24˝
Universal Toe Kick
Laminate
UMTK8
UMTK8 •4
Veneer
UWMTK8
UWMTK8 •4
• Laminate, 5 7/16” high x 96” long x 3/16”
thick MDF (Medium Density Fiberboard)
• Veneer, 5 7/16” high x 96” long x 5/32”
thick vennered plywood
•
Matching easy clean laminate on one side
• Grain direction runs lengthwise (when
applicable)
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
4ROT
1FWROT
2FWROT
2DROT
4DROT
2DFWROT
CFO
96˝
5 / ˝
Gray color coding indicates
new product, size or code
